| Year Introduced |
2012 |
|
| Megapixels |
20.2 |
|
| Total Pixels |
20.6 |
|
| Sensor Size |
35.8 x 23.9mm |
|
| Pixel Dimensions |
5472 x 3648 |
|
| Pixel Size |
6.54µm |
|
| Diffraction-Limited Aperture |
f/10.5 |
|
| Sensor Stabilization |
N |
|
| Lens Mount |
EF (excludes EF-S lenses), TS-E, MP-E |
|
| FOVCF |
1.0x |
|
| Image Processor |
DIGIC 5+ |
|
| |
| Type |
TTL-CT-SIR with a dedicated CMOS sensor |
|
| Points |
11 points (f/5.6 cross type at center, extra sensitivity at f/2.8) |
|
| Working Range |
EV -3 - 18 (at 23°C & ISO100) |
|
| Modes |
One Shot
AI Focus
AI Servo |
|
| Point Selection |
Automatic selection
Manual selection
AF points can be selected separately for vertical and horizontal shooting |
|
| Microadjustment |
C.Fn II-9
+/- 20 steps ( wide and tele setting for Zooms)
Adjust all lenses by same amount
Adjust up to 40 lenses individually
Adjustments remembered for lens by serial number |
|
| |
| Metering Modes |
TTL full aperture metering with 63 zone Dual Layer SPC
(1) Evaluative metering (linked to All AF point)
(2) Partial metering (approx. 8% of viewfinder at centre)
(3) Spot metering (approx. 3.5% viewfinder at centre)
(4) Centre weighted average metering |
|
| Metering Range |
EV 1 - 20 (at 23°C with 50mm f/1.4 lens ISO100) |
|
| Exposure Comp |
+/-5 EV in 1/3 or 1/2 stop increments (can be combined with AEB). |
|
| AEB |
2, 3, 5 or 7 Shots +/-3 EV 1/3 or 1/2 stop increments |
|
| ISO Sensitivity |
Auto (100-25600), 100-25600 (in 1/3-stop or whole stop increments)
ISO can be expanded to L: 50, H1: 51200, H2: 102400
During Movie shooting: Auto (100-12800), 100-12800 (in 1/3-stop or whole stop increments) ISO can be expanded to H: 25600 |
|
| Shutter Speed |
30 - 1/4000 sec (1/2 or 1/3 stop increments), Bulb (Total shutter speed range. Available range varies by shooting mode) |
|
| WB Settings |
AWB, Daylight, Shade, Cloudy, Tungsten, White
Fluorescent light, Flash, Custom, Color Temperature Setting.
White balance compensation:
1. Blue/Amber +/-9
2. Magenta/ Green +/-9. |
|
| Custom WB |
Yes, 1 setting can be registered |
|
| |
| Type |
Pentaprism |
|
| Coverage |
Approx. 97% |
|
| Magnification |
Approx. 0.71x |
|
| Eyepoint |
Approx. 21mm |
|
| Information |
AF information: AF points, focus confirmation light.
Exposure information: Shutter speed, aperture value, ISO speed (always displayed), AE lock, exposure level/compensation, spot metering circle, exposure warning, AEB.
Flash information: Flash ready, high-speed sync, FE lock, flash exposure compensation.
Image information: Highlight tone priority (D+), maximum burst (2-digit display), card
information
Battery check: Composition information
Electronic level
Warning symbol: Displayed if any of the following is set: Monochrome, white balance
correction, expanded ISO speed, or spot metering. |
|
| DOF Preview |
Yes, with Depth of Field preview button. |
|
| Eyepiece Shutter |
On strap |
|
| |
| Type |
3.0" (7.7cm) Clear View TFT, approx. 1040K dots |
|
| Coating |
Dual Anti-reflection |
|
| Brightness Adj |
Adjustable to one of seven levels |
|
| Display Options |
(1) Quick Control Screen
(2) Camera settings
(3) Electronic Level |
|
| |
| Built-in GN |
N/A (ISO 100, meters) |
|
| Built-in Coverage |
N/A |
|
| Built-in Recycle Time |
N/A |
|
| Modes |
E-TTL II Auto Flash, Metered Manual |
|
| X-Sync |
1/180sec |
|
| Exposure Compensation |
+/- 3EV in 1/2 or 1/3 increments |
|
| Hot Shoe/PC Terminal |
Yes / No |
|
| External Flash Comp |
E-TTL II with EX series Speedlites, wireless multi-flash support |
|
| External Flash Control |
Via camera menu |
|
| |
| Shooting Modes |
Scene Intelligent Auto, No Flash, Creative Auto, Portrait, Landscape, Close-up, Sports, Night Portrait, Handheld Night Scene, HDR Backlight Control, Program AE , Shutter priority AE, Aperture priority AE, Manual |
|
| Picture Styles |
Auto, Standard, Portrait, Landscape, Neutral, Faithful, Monochrome, User Defined (x3) |
|
| Image Processing |
Highlight Tone Priority
Auto Lighting Optimizer (4 settings)
Long exposure noise reduction
High ISO speed noise reduction (4 settings)
Multi Shot Noise Reduction
Auto Correction of Lens Peripheral illumination
Chromatic aberration correction
Resize to M, S1, S2 or S3
RAW image processing - during image Playback only
Multiple exposure
HDR images |
|
| Drive Modes |
Single, Continuous, Self timer (2s+remote, 10s +remote), Silent single shooting, Silent continous shooting |
|
| Continuous Shooting |
Max. Approx. 4.5fps. (speed maintained for up to 1250 images (JPEG) or 17 images (RAW)) (with UHS-I card) |
|
| Shutter Lag |
<60ms |
|
| Viewfinder Blackout |
N/A |
|
| |
| FrameRate |
30 fps |
|
| Focusing |
Manual Focus (Magnify the image 5x or 10x at any point on screen)
Autofocus: Quick mode, Live mode, Live Face detection mode |
|
| Metering |
Real-time evaluative metering with image sensor
Active metering time can be changed |
|
| Display Options |
Grid overlay (x3), Histogram, Aspect ratios, Electronic Level |
|
| |
| Still ImageType |
JPEG: Fine, Normal (Exif 2.21 [Exif Print] compliant) / Design rule for Camera File system (2.0),
RAW: RAW, M-RAW, S-RAW (14bit, Canon original RAW 2nd edition),
Digital Print Order Format [DPOF] Version 1.1 compliant |
|
| Image Size |
JPEG: (L) 5472x3648, (M) 3468x2432, (S1) 2736x1824, (S2) 1920x1280, (S3) 720x480
RAW: (RAW) 5472x3648, (M-RAW) 4104x2736, (S-RAW) 2736x1824 |
|
| Movie Type |
MOV (Video: H.264 Intra frame / inter frame, Sound: Linear PCM, recording level can be manually adjusted by user) |
|
| Movie Size |
1920 x 1080 (29.97, 25, 23.976 fps) intra or inter frame
1280 x 720 (59.94, 50 fps) intra or inter frame
640 x 480 (59.94, 50 fps) inter frame |
|
| Movie Length |
Max duration 29min 59sec |
|
| |
| Wireless Features |
Built-in Wi-Fi |
|
| GPS |
Built-in |
|
| Custom Functions |
21 Custom Functions |
|
| LCD Panel / Illumination |
Yes / Yes |
|
| Water & Dust Resistance |
Yes (equal to EOS-1N) |
|
| Sound Memo |
No |
|
| |
| Computer Interface |
Hi-Speed USB |
|
| Other Interface |
HDMI mini output, Video output (PAL/ NTSC), External microphone (Stereo mini jack) |
|
| |
| Memory Type |
SD, SDHC or SDXC (UHS-I) card |
|
| |
| Battery |
Rechargeable Li-ion Battery LP-E6 (supplied) |
|
| Battery Life |
Approx. 1090 (at 23°C, AE 50%, FE 50%)
980 (at 0°C, AE 50%, FE 50%) |
|
| Power Supply Battery Chargers |
AC Adapter Kit ACK-E6, Battery charger LC-E6, Car Battery charger CBC-E6 |
|
| |
| Body Materials |
Magnesium Alloy front and rear body covers. Polycarbonate top cover |
|
| Shutter Durability Rating |
100,000 |
|
| Operating Environment |
0 – 40 °C, 85% or less humidity |
|
| Dimensions Inches |
5.7 x 4.4 x 2.8" (144.5 x 110.5 x 71.2mm) |
|
| CIPA Weight |
26.6 oz (755g) |
|
| |
| Viewfinder |
Eyecup Eb, E-series Dioptric Adjustment Lens with Rubber Frame Eb, Eyepiece Extender EP-EX15, Focusing Screens Eg (with Grid Eg-D, Super Precision Matte Eg-S), Angle Finder C |
|
| Wireless File Transmitter |
Built in |
|
| Compatible Lenses |
All EF lenses (excludes EF-S lenses), TS-E and MP-E lenses |
|
| Battery Grip |
BG-E13 Buy ► |
|
| Remote |
Remote control with N3 type contact, Wireless Controller LC-5, Remote Controller RC-6 |
|
| Other |
Hand Strap E2, GP-E2 |
