| Body color |
Black |
| Sensor* |
• 23.1 x 15.4 mm CMOS sensor
• Nikon DX format (1.5x FOV crop)
• 14.2 million effective pixels*
• RGB Color Filter Array
• 12-bit A/D converter |
| Anti-dust measures |
• Image sensor cleaning system
• Airflow control system
• Image dust off from reference frame (using optional Capture NX software) |
| Image sizes* |
• 4608 x 3072 (L)*
• 3456 x 2304 (M)*
• 2304 x 1536 (S)* |
| Image quality * |
• NEF (12-bit compressed RAW)
• JPEG fine (1:4)
• JPEG normal (1:8)
• JPEG basic (1:16)
• NEF (RAW) + Fine JPEG* |
| Movie sizes* |
• 1920 x 1080 24p*
• 1280 x 720 30p*
• 1280 x 720 25p*
• 1280 x 720 24p*
• 640 x 424 24p* |
| Movie format * |
• MOV, H.264, mono sound recording (PCM) |
| Color space |
• sRGB
• Adobe RGB |
| Lens mount |
Nikon F mount (with AF contacts) |
| Lens compatibility |
• AF-S, AF-I
• Other Type G or D AF Nikkor
• Other AF Nikkor/AI-P Nikkor
• Type D PC Nikkor
• Non-CPU
• IX Nikkor/AF Nikkor for F3AF
• AI-P NIKKOR
-All functions supported
- All functions supported except autofocus
- All functions supported except autofocus and 3D Color Matrix Metering II
- All functions supported except some shooting modes
- Can be used in mode M, but exposure meter does not function; electronic range finder can be used if maximum aperture is f/5.6 or faster
- Cannot be used
-All functions supported except 3D color matrix metering II
|
| Autofocus |
• 11 area TTL phase detection
• Nikon Multi-CAM1000 autofocus module
• Detection range: EV -1 to +19 (ISO 100 equivalent, at normal temperature)
• Manual focus [M], Electronic range finding supported |
| Lens servo* |
• Single-servo AF (AF-S)
• Continuous-servo AF (AF-C)
• Automatic AF-S/AF-C (AF-A)
• Full time AF (AF-F)*
• Manual focus (MF) |
| AF Area mode |
• Single Area AF
• Dynamic Area AF
• Auto Area AF
• 3D Tracking (11 points)
• Closest Subject Priority Dynamic Area AF |
| Focus tracking |
Predictive focus tracking automatically activated according to subject status in continuous-servo AF |
| Focus area |
Can be selected from 11 focus points |
| Focus lock |
Focus can be locked by pressing shutter-release button halfway (single-servo AF) or by pressing AE-L/AF-L button |
| AF Assist |
White light lamp |
| Exposure mode* |
• Auto
- Auto
- Flash off
• Scene Modes
  Portrait
Landscape
Child
Sports
Close up
 Night portrait
• Programmed auto (P) with flexible program
• Shutter-priority auto (S)
• Aperture priority auto (A)
• Manual (M)
• GUIDE mode
• Easy operation
Auto
No flash
Distant subjects
Close ups
Sleeping faces
Moving subjects
Landscapes
Portraits
Night portrait
• Advanced mode
Soften backgrounds (aperture priority)
Bring more into focus (aperture priority)*
Freeze motion (people) (shutter priority)
Freeze motion (vehicles) (shutter priority)
Show water flowing (shutter priority)*
• Use a timer / quiet shutter |
| Metering |
TTL exposure metering using 420-pixel RGB sensor
• Matrix :3D color matrix metering II (type G and D lenses); color matrix metering II (other CPU lenses)
• Center-weighted: Weight of 75% given to a 8mm circle in center of frame
• Spot: Meters 3.5 mm circle (about 2.5% of frame) centered on active focus area |
| Metering range |
• EV 0 to 20 (3D color matrix or center-weighted metering)
• EV 2 to 20 (spot metering) |
| Meter coupling |
CPU coupling |
| Exposure comp. |
• +/- 5.0 EV
• 1/3 EV steps |
| AE Lock |
Exposure locked at detected value with AE-L/AF-L button |
| AE Bracketing |
None |
| Sensitivity* |
• Auto
• ISO 100
• ISO 200
• ISO 400
• ISO 800
• ISO 1600
• ISO 3200*
• ISO 6400 (Hi1)*
• ISO 12800 (Hi2)* |
| Auto ISO options* |
• On/Off
• Maximum ISO (200 to Hi2)*
• Minimum shutter speed (1 to 1/2000 sec) |
| Shutter |
• Electronically-controlled vertical-travel focal-plane shutter
• 30 to 1/4000 sec (1/3 EV steps)
• Flash X-Sync: up to 1/200 sec
• Bulb |
| White balance |
Auto (TTL white-balance with 420 pixels RGB sensor)
• Twelve manual modes with fine-tuning
• Incandescent
• Fluorescent
Sodium-vapor lamps
Warm-white fluorescent
White fluorescent
Cool-white fluorescent
Day white fluorescent
Daylight fluorescent
Daylight fluorescent
Mercury-vapor lamps
• Direct sunlight
• Flash
• Cloudy
• Shade
• Preset white balance (immediate or from photo) |
| WB fine tuning |
Yes, (except preset manual) |
| Image parameters |
• Picture controls: Standard, Neutral, Vivid, Monochrome, Portrait, Landscape
• Quick Adjust: 5 settings (adjusts Sharpening, Contrast and Saturation by preset amounts)
• Sharpening: Auto, 10 levels
• Contrast: Auto, 7 levels
• Brightness: 3 levels*
• Saturation: Auto, 7 levels
• Hue: 7 levels |
| Viewfinder |
• Optical fixed eye-level
• Pentamirror type
• Built-in dioptre adjustment (-1.7 to +0.5 m-1)
• Eye point: 18 mm (at -1.0 m-1)
• Frame coverage 95% (approx.)
• Viewfinder magnification approx. 0.8x with 50mm lens at infinity; -1.0 m-1
• Focusing screen: Type B BriteView clear matte screen Mark VII* |
| LCD monitor |
• 3.0" TFT LCD
• 230,000 pixel |
| Built-in flash |
• Auto, Portrait, Child, Close-up, Night portrait
• Auto flash with auto pop-up,
• Manual pop-up in P, S, A or M modes
• Guide number approx. 12/39 at ISO 100 (m/ft)
• Guide number approx. 13/43 at ISO 100 (m/ft) in manual mode |
| Sync contact |
X-contact only; flash synchronization at shutter speeds of up to 1/200 sec |
| Flash control |
• TTL flash control by 420-segment RGB sensor. i-TTL balanced fill-flash for digital SLR and standard i-TTL fill-flash for digital SLR available when CPU lens is used with built-in flash, SB-400, SB-800, and SB-600
• Auto aperture with SB-800 and CPU lenses
• Non-TTL auto with SB-800, 80DX, 28DX, 28, 27 and 22s
• Range-priority manual with SB-800 |
| Flash mode |
• Auto, Portrait, Child, Close-up: Auto, auto with red-eye reduction; fill-flash and red-eye reduction available with optional Speedlight
• Night portrait: Auto, auto slow sync, auto slow sync with red-eye reduction; slow sync and slow sync with red-eye reduction available with optional Speedlight
• Landscape, Sports: Fill-flash and red-eye reduction available with optional Speedlight
• P, A modes: Fill flash, rear-curtain with slow sync, slow sync, slow sync with red-eye reduction, red-eye reduction
• S, M modes: Fill flash, rear-curtain sync, red-eye reduction |
| Flash compensation |
• -3 to +1 EV
• 1/3 steps |
| Nikon Creative Lighting system |
• Advanced Wireless Lighting supported with SB-900, SB-800 or SU-800 as commander |
| Shooting modes |
• Single frame shooting (S) mode
• Continuous shooting (C) mode: approx. 3.0 frames per second
• Self-timer
• Quiet release (Q) mode |
| Continuous buffer |
• Unknown |
| Self-timer |
• 2 or 10 sec |
| Remote control* |
• Using optional MC-DC2 cable via GPS socket* |
| Text input |
Up to 36 characters of alphanumeric text input is available with LCD monitor and multi-selector; stored in EXIF header |
| Playback functions |
• Full frame
• Thumbnail (4, 9, or 72 images or calendar)
• Playback with Playback zoom
• Slide Show
• Histogram Display
• Highlights
• Auto Image Rotation
• Image Comment (up to 36 characters) |
| Orientation sensor |
Yes (Rotates user interface when using camera in portrait orientation) |
| Storage |
• SD / SD HC / SDXC
• FAT / FAT32
• Supports firmware update via SD card |
| Video output |
NTSC or PAL selectable |
| Connectivity |
• USB 2.0 (Hi-Speed)
• Mass storage / PTP selectable
• A/V out
• HDMI out
• DC-IN (optional AC adapter and adapter connector) |
| Languages* |
Czech, Chinese (Simplified and Traditional), Danish, Dutch, English, Finnish, French, German, Indonesian, Italian, Japanese, Korean, Norwegian, Polish, Portuguese, Russian, Spanish, Swedish, Turkish |
| Power* |
Lithium-Ion battery pack EN-EL14 (7.4 V, 1030 mAh) |
| Working environment |
• 0 to 40°C (32 to 104°F)
• Less than 85% humidity |
| Dimensions |
124 x 96 x 75 mm (4.9 x 3.8 x 3.0 in) |
| Weight (no batt) |
455g (1.0 lb) |
| Weight (inc. batt) |
505g (1.1 lb) |
| Supplied accessories |
• Rechargeable Li-ion Battery EN-EL14
• Quick Charger MH-24
• Eyepiece Cap DK-5
• Rubber Eyecup DK-20
• USB Cable UC-E4
• Video Cable EG-D100
• Camera Strap AN-DC3
• Accessory Shoe Cover BS-1
• Body Cap BF-1A, Software Suite CD-ROM |
| Optional accessories |
Remote Control MC-DC2, Capture NX2, Camera Control Pro, AC Adapter Connector EP-5, AC Adapter EH-5, Video Cable EG-D100, Semi Soft-Case CF-DC1, Speedlight SB-900/600/400/T041/R1C1 |
