Canon EOS 90D Body

Key Features:

32.5MP APS-C CMOS Sensor
DIGIC 8 Image Processor
UHD 4K30p & Full HD 120p Video Recording
3" 1.04m-Dot Vari-Angle Touchscreen LCD
45-Point All Cross-Type AF System
Dual Pixel CMOS AF with 5481 AF Points
Up to 10-fps Shooting, ISO 100-25600
Built-In Wi-Fi and Bluetooth
EOS iTR AF, Electronic Shutter Function
220,000-Pixel AE Metering Sensor
In-camera 4K time-lapses can be produced, along with 4K frame grabs for effectively shooting 8MP stills at up to 30 fps.
A revised 220000-pixel AE metering sensor benefits both autofocus and exposure metering precision and enables Color Tracking for more accurately detecting skin colors.
EOS iTR autofocus provides face detection for refined focus control when shooting portraits.
Electronic shutter function permits working with shutter speeds up to 1/16000 of a second.

Situated as a versatile camera with capable photo and video traits, the Canon EOS 90D is a sleek DSLR also characterized by its high-resolution 32.5MP APS-C CMOS sensor. This updated sensor design achieves enhanced image clarity, resolution, and dynamic range, along with adept sensitivity to ISO 25600 and low noise to suit working in a variety of situations. Combined with advanced image processing, this sensor is also capable of outputting UHD 4K30p and Full HD 120p video, as well as supporting continuous stills shooting rates up to 10 fps. When working with the optical viewfinder, an apt 45-point all cross-type AF system affords fast performance in a range of lighting conditions for tracking moving subjects and working in low light, while the 5481-point Dual Pixel CMOS AF system benefits live-view shooting and movie recording by providing a smooth, natural focusing quality akin to the way a camcorder acquires focus. Complementing the imaging capabilities, the 90D sports a vari-angle touchscreen LCD for intuitive control and compositional freedom, and an optical pentaprism viewfinder provides a bright, clear, and realistic viewing means characteristic of the DSLR shooting experience. Additionally, built-in Wi-Fi and Bluetooth connectivity allow you to pair mobile devices with the camera to wirelessly transfer files for sharing your photos and movies online.

Suitable for - Wildlife/ Sports Photography

Type	APS-C CMOS
Effective Pixels	Approx. 32.5 megapixels
Total Pixels	Approx. 34.4 megapixels
Aspect Ratio	3:2
Sensor Cleaning	EOS integrated cleaning system
Colour Filter Type	Primary Colour
IMAGE PROCESSOR
Type	DIGIC 8
LENS
Lens Mount	EF/EF-S
Focal Length	Equivalent to 1.6x the focal length of the lens
FOCUSING
Live View Shooting	Dual Pixel CMOS AF
Viewfinder Shooting	TTL secondary image-registration, phase-difference detection with the dedicated AF sensor
AF System/ Points	45 cross-type AF points
AF working range	EV -3 - 18 (at 23°C & ISO100)
AF Modes	Spot AF 1-Point AF Zone AF Large Zone AF Face Priority AF AI Focus One Shot AI Servo Movie Servo AF Continuous AF Eye Detection AF
AF area (live shooting)	Horizontal: approx. 88%, Vertical: approx. 100%
AF Lock	Locked when shutter button is pressed half way
AF Assist Beam	Intermittent firing of built-in flash or emitted by optional dedicated Speedlite
AF Micro-adjustment	Adjust all lenses by same amount Adjust by lens
Manual Focus	Selected on lens
EXPOSURE CONTROL
Metering modes	Viewfinder shooting: Approx 220,000 pixels RGB+IR metering sensor 216-zone (18x12) TTL full-aperture metering Live View shooting and Move recording: 384-zone metering with image sensor
Metering Range	EV 1-20 (optical viewfinder) EV -2 – 20 (Live View) EV 0 – 20 (Movie recording)
AE Lock	Auto: In One-shot AF mode with evaluative metering exposure is locked when focus is achieved. Manual: By AE lock button in P, TV, AV and M mode.
Exposure Compensation	+/-5 EV in 1/3 or 1/2 stop increments (viewfinder) +/-3 EV in 1/3 or 1/2 stop increments (Live View/ Movie)
AEB	+/-3 EV 1/3 or 1/2 stop increments
ISO Sensitivity (8)	Auto (100-12800min / 100-25600 max) in 1-stop increments. Manual (100-25600) in 1/3-stop increments, expanded to 51200 equivalent. Minimum limit may change depending on the lens
SHUTTER
Type	Vertical-travel mechanical focal-plane shutter, electronically controlled at all speeds
Speed	Creative Zone: 1/16000 – 30 sec, bulb Basic Zone: 1/8000 – 1 sec Available range varies by shooting mode
IMAGE SENSOR
Type	APS-C CMOS
Effective Pixels	Approx. 32.5 megapixels
Total Pixels	Approx. 34.4 megapixels
Aspect Ratio	3:2
Sensor Cleaning	EOS integrated cleaning system
Colour Filter Type	Primary Colour
IMAGE PROCESSOR
Type	DIGIC 8
LENS
Lens Mount	EF/EF-S
Focal Length	Equivalent to 1.6x the focal length of the lens
FOCUSING
Live View Shooting	Dual Pixel CMOS AF
Viewfinder Shooting	TTL secondary image-registration, phase-difference detection with the dedicated AF sensor
AF System/ Points	45 cross-type AF points
AF working range	EV -3 - 18 (at 23°C & ISO100)
AF Modes	Spot AF 1-Point AF Zone AF Large Zone AF Face Priority AF AI Focus One Shot AI Servo Movie Servo AF Continuous AF Eye Detection AF
AF area (live shooting)	Horizontal: approx. 88%, Vertical: approx. 100%
AF Lock	Locked when shutter button is pressed half way
AF Assist Beam	Intermittent firing of built-in flash or emitted by optional dedicated Speedlite
AF Micro-adjustment	Adjust all lenses by same amount Adjust by lens
Manual Focus	Selected on lens
EXPOSURE CONTROL
Metering modes	Viewfinder shooting: Approx 220,000 pixels RGB+IR metering sensor 216-zone (18x12) TTL full-aperture metering Live View shooting and Move recording: 384-zone metering with image sensor
Metering Range	EV 1-20 (optical viewfinder) EV -2 – 20 (Live View) EV 0 – 20 (Movie recording)
AE Lock	Auto: In One-shot AF mode with evaluative metering exposure is locked when focus is achieved. Manual: By AE lock button in P, TV, AV and M mode.
Exposure Compensation	+/-5 EV in 1/3 or 1/2 stop increments (viewfinder) +/-3 EV in 1/3 or 1/2 stop increments (Live View/ Movie)
AEB	+/-3 EV 1/3 or 1/2 stop increments
ISO Sensitivity (8)	Auto (100-12800min / 100-25600 max) in 1-stop increments. Manual (100-25600) in 1/3-stop increments, expanded to 51200 equivalent. Minimum limit may change depending on the lens
SHUTTER
Type	Vertical-travel mechanical focal-plane shutter, electronically controlled at all speeds
Speed	Creative Zone: 1/16000 – 30 sec, bulb Basic Zone: 1/8000 – 1 sec Available range varies by shooting mode
INTERFACE
Computer	Hi-Speed USB
Other	Video output (PAL/ NTSC) (integrated with USB terminal), HDMI mini output (Typce C only, CEC not supported), External microphone (3.5mm Stereo mini jack), Headphone socket (Stereo mini jack)
DIRECT PRINT
Canon Printers	Canon Compact Photo Printers and PIXMA Printers supporting PictBridge
PictBridge	Yes
STORAGE
Type	SD, SDHC or SDXC (UHS-II) card
SUPPORTED OPERATING SYSTEMS
PC & Macintosh	Windows 10 / 8.1 / 8 / 7() With Microsoft .NET Framework 4.5 is installed. Mac OS X 10.9, 10.10, 10.11
SOFTWARE
Image Processing	Digital Photo Professional 4.4.0 (RAW Image Processing)
Other	EOS Utility Canon Camera Connect App
INTERFACE
Computer	Hi-Speed USB
Other	Video output (PAL/ NTSC) (integrated with USB terminal), HDMI mini output (Typce C only, CEC not supported), External microphone (3.5mm Stereo mini jack), Headphone socket (Stereo mini jack)
DIRECT PRINT
Canon Printers	Canon Compact Photo Printers and PIXMA Printers supporting PictBridge
PictBridge	Yes
STORAGE
Type	SD, SDHC or SDXC (UHS-II) card
SUPPORTED OPERATING SYSTEMS
PC & Macintosh	Windows 10 / 8.1 / 8 / 7() With Microsoft .NET Framework 4.5 is installed. Mac OS X 10.9, 10.10, 10.11
SOFTWARE
Image Processing	Digital Photo Professional 4.4.0 (RAW Image Processing)
Other	EOS Utility Canon Camera Connect App
INTERFACE
Computer	Hi-Speed USB
Other	Video output (PAL/ NTSC) (integrated with USB terminal), HDMI mini output (Type C only, CEC not supported), External microphone (3.5mm Stereo mini jack), Headphone socket (Stereo mini jack)
DIRECT PRINT
Canon Printers	Canon Compact Photo Printers and PIXMA Printers supporting PictBridge
PictBridge	Yes
STORAGE
Type	SD, SDHC or SDXC (UHS-II) card
SUPPORTED OPERATING SYSTEMS
PC & Macintosh	Windows 10 / 8.1 / 8 / 7() With Microsoft .NET Framework 4.5 is installed. Mac OS X 10.9, 10.10, 10.11
SOFTWARE
Image Processing	Digital Photo Professional 4.4.0 (RAW Image Processing)
Other	EOS Utility Canon Camera Connect App
POWER SOURCE
Batteries	Rechargeable Li-ion Battery LP-E6N (supplied)
Battery life	Approx. 1860 (at 23°C)- Not including battery packs
Battery Indicator	6 levels + percentage
Power saving	Power turns off after 30 sec, 1, 2, 4, 8, 15min
Power Supply & Battery Chargers	AC Adapter AC-E6(N), DC coupler: DR-E6, Battery charger LC-E6/LC-E6E
ACCESSORIES
Viewfinder	Eyecup Eb, E-series Dioptric Adjustment Lens, Eyepiece Extender EP-EX15, Angle Finder C
Wireless File Transmitter	Built in Wi-Fi transmission GPS Receiver GP-E2, Wireless remote BR-E1, Remote Controller RC-6, Remote Switch RS-60E3, Timer Remote Controller TC-80N3, Remote Controller Adapter RA-E3
Lenses	All EF and EF-S lenses
Flash	ST-E2, ST-E3-RT, EL-100, 270EX II, 430EX III RT/ 430 EX III, 470EX-AI, 600EX II-RT, Macro Ring Lite MR-14EX II, Macro Twin Lite MT-26EX-RT
Battery	Battery Park LP-E6N Battery Charger LC-E6 or LC-E6E Car Battery Cable CB-570 Care Battery Charger CBC-E6 Grip: BG-E14
Other	Hand Strap E2 Battery Magazine BGM-E14L / BGM-E14A
PHYSICAL SPECIFICATIONS
Body Materials	Aluminum alloy and polycarbonate resin with glass fibre
Operating Environment	0 – 40 °C, 85% or less humidity
Dimensions (WxHxD)	140.7 x 104.8 x 76.8mm
Weight (body only)	Approx. 701g (CIPA testing standard, including battery and memory card)
