Optical Design
|
Refractor
|
|
Aperture
|
70mm
|
|
Focal Length
|
700mm
|
|
Focal Ratio
|
f/10
|
|
Focal Length of Eyepiece 1
|
25mm
|
|
|
|
|
Focal Length of Eyepiece 2
|
10mm
|
|
|
|
|
Barlow Lens
|
2x (1.25″)
|
|
Finderscope
|
StarPointer™ red dot finderscope
|
|
Star Diagonal
|
Erect image 90° (1.25″)
|
|
Optical Tube
|
Aluminum
|
|
Highest Useful Magnification
|
165x
|
|
Lowest Useful Magnification
|
10x
|
|
Limiting Stellar Magnitude
|
11.7
|
|
Resolution (Rayleigh)
|
1.99 arc seconds
|
|
Resolution (Dawes)
|
1.66 arc seconds
|
|
Light Gathering Power (Compared to human eye)
|
100x
|
|
Optical Coatings
|
Fully-Coated glass optics
|
|
Optical Tube Length
|
812.8mm
|
|
Optical Tube Diameter
|
76mm
|
|
Optical Tube Weight
|
1.63 kg
|
|
Dovetail
|
None
|
|
MOUNT INFO:
|
|
|
Mount Type
|
Manual Alt-Azimuth
|
|
Height adjustment range (includes mount and tripod)
|
Aluminum, 1320.8mm max height
|
|
Tripod Leg Diameter
|
31.75mm steel
|
|
Accessory Tray
|
Yes
|
|
Tripod Weight
|
1.72 kg
|
|
Slew Speeds
|
Manual
|
|
GPS
|
Uses phone’s GPS
|
|
Dovetail Compatibility
|
CG-5 Dovetail bar
|
|
Power Requirements
|
None (Recommend PowerTank Glow to keep phone charged while using app)
|
|
Alignment Procedures
|
Use StarSense Explorer app
|
|
Software
|
StarSense Explorer app | SkyPortal app | Celestron Starry Night Basic Edition Software
|
|
Total Kit Weight
|
3.35 kg
|
|
Included Items
|
Telescope tube | Mount/tripod (preassembled) | 25mm & 10mm eyepieces | Erect image diagonal | 2x Barlow lens | StarPointer finderscope | Accessory tray | StarSense Explorer phone dock
|
