DJI Focus Pro LiDAR

Key Features

Designed for DJI RS 3/4 Pro Gimbals
76,800 Ranging Points
Built-In Camera with 70° Field of View
65.6' Detection Range, 30mm Focal Length
Wide-Angle and Telephoto Modes
Flex Spot, ActiveTrack, Object Detect
Works with Focus Pro Motor for Autofocus
USB-C Input Ports
Cold Shoe Mount, 1/4"-20 Thread

Designed for both the RS 3 Pro and RS 4 Pro gimbal stabilizers, the DJI Focus Pro LiDAR unit makes achieving intelligent autofocus intuitive and easy for solo cinematographers. The rangefinder unit makes focusing on objects in motion a breeze thanks to its expanded 76,800 ranging points, 30 Hz refresh rate, and 65.6' maximum detection area. This allows it to support both wide-angle and telephoto lens configurations.

Compatibility	DJI RS 3 Pro / RS 4 Pro / Focus Pro Grip
Resolution	1920 x 1440
Frame Rate	30 fps
Field of View	57.4° (Horizontal) 44.6° (Vertical)
Range	1.6 to 65.6' / 0.5 to 20 m

Inputs / Outputs

USB I/O

2 x USB-C Female Input

Power

Power Source	USB
DC Input Power	6.6 to 17.2 VDC
Power Consumption	6.3 W (Typical) 6.8 W (Maximum)

Environmental

Environmental Resistance	No
Operating Temperature	-4 to 113°F / -20 to 45°C

Physical

Mounting	1x Cold Shoe 1x 1/4"-20 Thread
Color	Black
Cable Length	11.8" / 30 cm
Dimensions	2.7 x 2.2 x 1" / 68 x 57 x 25 mm
Weight	4.9 oz / 140 g

Packaging Info

Package Weight	0.43 lb
Box Dimensions (LxWxH)	4.6 x 3.1 x 2.9"
