Maximum Takeoff Weight |
958 g |
Maximum Horizontal Speed |
75.6 km/h |
Maximum Ascent Speed |
28.8 km/h |
Maximum Descent Speed |
21.5 km/h |
Maximum Wind Resistance |
43.1 km/h |
Flight Ceiling |
6000 m |
Maximum Flight Time |
43 Minutes |
Maximum Hover Time |
37 Minutes |
Maximum Tilt Angle |
35° |
Hovering Accuracy |
Vision Positioning |
Vertical: ±0.3' / 0.1 m |
Horizontal: ±1.0' / 0.3 m |
GNSS |
Vertical: ±1.6' / 0.5 m |
Horizontal: ±1.6' / 0.5 m |
|
|
Image Sensor |
4/3"-Type CMOS |
Sensor Resolution |
Effective: 20 Megapixel (5280 x 3956) |
Focal Length |
24mm (35mm Equivalent) |
Field of View |
84° |
Maximum Aperture |
f/2.8 |
Minimum Aperture |
f/11 |
Minimum Focus Distance |
3.3' / 1 m |
ISO Sensitivity |
Video |
100 to 12,800 |
Shutter Speed |
1/8000 to 8 Seconds |
Video Format |
5120 x 2700p at 24/25/30/48/50 fps (MOV/MP4 via H.264/AVC, H.265/HEVC, MPEG-4) |
Still Image Support |
DNG / JPEG |
20 MP (5280 x 3956) |
Internal Storage |
1 TB |
Media/Memory Card Slot |
Single Slot: microSD/microSDHC/microSDXC [512 GB Maximum] |
Photo Modes |
Auto-Exposure Bracketing (AEB), Burst Shooting, Interval, Single Shot |
|
|
Telephoto Lens |
Image Sensor: 1/1.3" CMOS |
Effective Pixels: 48 MP |
FOV: 35° |
Format Equivalent: 70 mm |
Aperture: f/2.8 |
Minimum Focus: 9.8' / 3 m |
Shutter Speed: 1/8000 to 2 Seconds |
Maximum Image Size: 8064 x 6048 |
Supported File System: exFAT |
Digital Zoom: 3 to 7x (Normal Video Mode & Explore Mode) |
ISO Range |
(Video, Normal and Slow Motion): 100-6400 (Normal), 400-1600 (D-Log), 100-1600 (D-Log M), and 100-1600 (HLG) |
(Night): 800-12,800 (Normal) |
(Photo): 100-6400 |
Still Image |
(Single Shot): 12 MP or 48 MP |
(Burst Shooting): 12 MP or 48 MP, 3/5/7 Frames |
(Automatic Exposure Bracketing): 12 MP or 48 MP, 3/5 Frames at 0.7 EV Step |
(Timed, 12 MP): 2, 3, 5, 7, 10, 15, 20, 30, 60 Seconds |
(Timed, 48 MP): 7, 10, 15, 20, 30, 60 Seconds |
Photo Format: JPEG, DNG (RAW) |
Video Resolution |
Apple ProRes 422 HQ, 422, and 422 LT |
(4K): 3840 × 2160 at 24, 25, 30, 48, 50, 60 FPS, H.264/H.265 |
(4K): 3840 × 2160 at 24, 25, 30, 48, 50, 60 FPS |
(FHD): 1920 × 1080 at 24, 25, 30, 48, 50, 60 FPS |
Video Format: MP4/MOV (MPEG-4 AVC/H.264, HEVC/H.265), MOV (Apple ProRes 422 HQ/422/422 LT) |
Video Bitrate |
Max (H.264/H.265): 200 Mb/s |
Max (Apple ProRes 422 HQ): 3772 Mb/s |
Max (Apple ProRes 422): 2514 Mb/s |
Max (Apple ProRes 422 LT): 1750 Mb/s |
Color Modes |
Normal: 10-bit 4:2:2 (Apple ProRes 422 HQ/422/422 LT) |
Normal: 8-bit 4:2:0 (H.264/H.265) |
HLG/D-Log M: 10-bit 4:2:2 (Apple ProRes 422 HQ/422/422 LT) |
HLG/D-Log M: 10-bit 4:2:0 (H.265) |
|
|
Telephoto Lens |
Image Sensor: 1/2" CMOS |
Effective Pixels: 12 MP |
FOV: 15° |
Format Equivalent: 166 mm |
Aperture: f/3.4 |
Minimum Focus: 9.8' / 3 m |
Shutter Speed: 1/8000 to 2 Seconds |
Maximum Image Size: 4000 x 3000 |
Supported File System: exFAT |
Digital Zoom: 7 to 28x (Normal Video Mode & Explore Mode) |
ISO Range |
(Video, Normal and Slow Motion): 100-6400 (Normal), 400-1600 (D-Log), 100-1600 (D-Log M), and 100-1600 (HLG) |
(Night): 800-12,800 (Normal) |
(Photo): 100-6400 |
Still Image |
(Single Shot): 12 MP |
(Burst Shooting): 12 MP, 3/5/7 Frames |
(Automatic Exposure Bracketing): 12 MP, 3/5 Frames at 0.7 EV Step |
(Timed, 12 MP): 2, 3, 5, 7, 10, 15, 20, 30, 60 Seconds |
Photo Format: JPEG, DNG (RAW) |
Video Resolution |
Apple ProRes 422 HQ, 422, and 422 LT |
(4K): 3840 × 2160 at 24, 25, 30, 48, 50, 60 FPS, H.264/H.265 |
(4K): 3840 × 2160 at 24, 25, 30, 50, 60 FPS |
(FHD): 1920 × 1080 at 24, 25, 30, 50, 60 FPS |
Video Format: MP4/MOV (MPEG-4 AVC/H.264, HEVC/H.265), MOV (Apple ProRes 422 HQ/422/422 LT) |
Video Bitrate |
Max (H.264/H.265): 200 Mb/s |
Max (Apple ProRes 422 HQ): 3772 Mb/s |
Max (Apple ProRes 422): 2514 Mb/s |
Max (Apple ProRes 422 LT): 1750 Mb/s |
Color Modes |
Normal: 10-bit 4:2:2 (Apple ProRes 422 HQ/422/422 LT) |
Normal: 8-bit 4:2:0 (H.264/H.265) |
Number of Axes |
3-Axis (Pitch (Tilt), Roll, Yaw (Pan)) |
Rotation Range |
Mechanical Range |
Pitch (Tilt): 190° (-140 to 50°) |
Roll: 100° (-50 to 50°) |
Yaw (Pan): 46° (-23 to 23°) |
Controllable Range |
Pitch (Tilt): 125° (-90 to 35°) |
Yaw (Pan): 10° (-5 to 5°) |
Follow Speed |
100°/s |
GNSS Support |
GPS, BeiDou, Galileo |
Vision System |
Downward / Upward / Forward / Backward / Left / Right |
Vision System Capabilities |
Forward |
Measurement Range: 1.6 to 65.6' / 0.5 to 20 m |
Detection Range: 1.6 to 656.2' / 0.5 to 200 m |
Max Speed: 33.6 mph / 15 m/s |
Field of View: 90° (Horizontal) / 103° (Vertical) |
Backward |
Measurement Range: 1.6 to 52.5' / 0.5 to 16 m |
Max Speed: 26.8 mph / 12 m/s |
Field of View: 90° (Horizontal) / 103° (Vertical) |
Lateral |
Measurement Range: 1.6 to 82.0' / 0.5 to 25 m |
Max Speed: 33.6 mph / 15 m/s |
Field of View: 90° (Horizontal) / 85° (Vertical) |
Upward |
Measurement Range: 0.7 to 32.8' / 0.2 to 10 m |
Max Speed: 13.4 mph / 6 m/s |
Field of View: 100° (Vertical) / 90° (Horizontal) |
Downward |
Measurement Range: 1.0 to 59.1' / 0.3 to 18 m |
Max Speed: 13.4 mph / 6 m/s |
Field of View: 130° (Vertical) / 160° (Horizontal) |
Operating Environment |
Surface with Clear Patterns at >15 lux |
Required Object Reflectivity |
>20% |
Operating Frequency |
2.4 GHz (2.400 to 2.4835) |
5.8 GHz (5.725 to 5.850) |
Maximum Operating Distance |
15 km |
Battery Chemistry |
Lithium-Ion |
Battery Capacity |
5000 mAh / 77 Wh |
Battery Configuration |
4 S / 17.6 V |
Charging Temperature |
41 to 104°F / 5 to 40°C |
Battery Weight |
335.5 g |
Rotor Configuration |
4 |
Operating Temperature |
14.0 to 104.0°F / -10.0 to 40.0°C |
Overall Dimensions |
3.9 x 3.8 x 9.1" / 98.0 x 95.4 x 231.1 mm (Folded) |
11.4 x 4.2 x 13.7" / 290.8 x 107.7 x 347.5 mm (Unfolded) |
Weight |
963 g |
