Performance
Maximum Horizontal Speed 35.8 mph / 16 m/s (S Mode)
22.4 mph / 10 m/s (N Mode)
13.4 mph / 6 m/s (C Mode)
Maximum Ascent Speed 11.2 mph / 5 m/s
Maximum Descent Speed 11.2 mph / 5 m/s
Maximum Wind Resistance 23.9 mph / 10.7 m/s
Flight Ceiling 2.5 Miles / 4000 m
Maximum Flight Time 34 Minutes
Maximum Hover Time 30 Minutes
Maximum Tilt Angle 40°
Hovering Accuracy ±1.0' / 0.3 m Horizontal with Vision Positioning
±0.3' / 0.1 m Vertical with Vision Positioning
±1.6' / 0.5 m Vertical with GPS
Maximum Angular Velocity 250°/s (Pitch)
Camera
Sensor Type 1/1.28"-Type CMOS Sensor
Sensor Resolution Effective: 48 Megapixel
Focal Length 24mm (35mm Equivalent)
Field of View 82.1°
Maximum Aperture f/1.7
Minimum Focus Distance 3.3' / 1 m
ISO Sensitivity Photo/Video
100 to 6400 in Manual, Auto Mode
Shutter Speed Electronic Shutter
2 to 1/8000 Seconds
Video Format 3840 x 2160p at 24/25/30/48/50/60 fps (150 Mb/s MOV/MP4 via H.264/AVC, H.265/HEVC)
2720 x 1530p at 24/25/30/48/50/60 fps (150 Mb/s MOV/MP4 via H.264/AVC, H.265/HEVC)
1920 x 1080p at 24/25/30/48/50/60/120 fps (150 Mb/s MOV/MP4 via H.264/AVC, H.265/HEVC)
Broadcast Resolution None
Still Image Support DNG / JPEG / Raw
48 MP (8064 x 6048)
12 MP (4032 x 3024)
12 MP (4032 x 2268)
Media/Memory Card Slot Single Slot: microSD/microSDHC/microSDXC (UHS-I) [512 GB Maximum / U3/V30 or Faster Recommended]
Photo Modes Auto-Exposure Bracketing (AEB), Interval, Single Shot
Gimbal
Number of Axes 3 (Pitch, Roll, Yaw)
Control Range Pitch: -135 to 80°
Roll: -135 to 45°
Yaw: -30 to 30°
Angular Speed Pitch: 100°/s
Control Accuracy ±0.01°
Flight Control System
GNSS Support GPS, BeiDou, Galileo
3D Object Detection
Operating Range Not Specified by Manufacturer
Vision System
Vision System Downward, Forward, Backward
Obstacle Sensory Range 1.3 to 82.0' / 0.4 to 25.0 m
Forward Field of View 106° (Horizontal)
90° (Vertical)
Backward Field of View 58° (Horizontal)
73° (Vertical)
Operating Environment Surface with Clear Patterns at >15 lux
Remote Controller / Transmitter
Operating Frequency 2.4 GHz (2.400 to 2.483)
5.8 GHz (5.725 to 5.850)
Maximum Operating Distance 7.5 Miles / 12 km
Transmitter Power 26 dBm (2.4 G)
26 dBm (5.8 G)
Flight Battery
Model Intelligent Flight Battery
Battery Chemistry Lithium-Ion Polymer (LiPo)
Battery Capacity 2453 mAh / 18.1 Wh
Battery Configuration 2 S / 7.38 V
Maximum Charging Power 37 W
Charging Temperature 41 to 104°F / 5 to 40°C
Weight 2.8 oz / 80.5 g
General
Rotor Configuration 4
Operating Temperature 32 to 104°F / 0 to 40°C
Diagonal Size 9.7" / 247 mm
Overall Dimensions 3.5 x 2.4 x 5.7" / 90.0 x 62.0 x 145.0 mm (Folded)
14.3 x 2.8 x 9.9" / 362.0 x 70.0 x 251.0 mm (Unfolded)
