Model Variations |
CS2731-BK |
Panel |
|
Type |
IPS |
Backlight |
Wide-Gamut LED |
Size |
27" / 68.5 cm |
Native Resolution |
2560 x 1440 (16:9 aspect ratio) |
Viewable Image Size (H x V) |
596.7 x 335.7 mm |
Pixel Pitch |
0.233 x 0.233 mm |
Pixel Density |
109ppi |
Grayscale Tones |
USB Type-C, DisplayPort, HDMI: 1,024 tones (a palette of 65 thousand tones) DVI: 256 tones (a palette of 65 thousand tones) |
Display Colors |
USB Type-C, DisplayPort, HDMI: 1.07 billion from a palette of 278 trillion DVI: 16.77 million from a palette of 278 trillion |
Viewing Angles (H / V, typical) |
178°, 178° |
Brightness (typical) |
350 cd/m2 |
Contrast Ratio (typical) |
1000:1 |
Response Time (typical) |
16 ms (Gray-to-gray) |
Color Gamut (typical) |
Adobe RGB: 99% |
Video Signals |
|
Input Terminals |
USB Type-C (DisplayPort Alt Mode, HDCP 1.3), DisplayPort (HDCP 1.3), HDMI (Deep Color, HDCP 1.4), DVI-D (HDCP 1.4) |
Digital Scanning Frequency (H / V) |
USB Type-C, DisplayPort, DVI: 26 - 89 kHz, 23 - 61 Hz HDMI: 15 - 89 kHz, 23 - 61 Hz |
USB |
|
Upstream |
USB 3.1 Gen 1: Type-C (DisplayPort Alt Mode, Power Delivery Source 60 W max.), Type-B |
Downstream |
USB 3.1 Gen 1: Type-A x 2 USB 2.0: Type-A x 2 |
Power |
|
Power Requirements |
AC 100 - 240 V, 50 / 60 Hz |
Typical Power Consumption |
34 W |
Maximum Power Consumption |
159 W |
Power Save Mode |
1.0 W or less |
Standby Mode |
1.0 W or less |
Features & Functions |
|
Digital Uniformity Equalizer |
Yes |
Preset Modes |
Color Mode (User, Adobe RGB, sRGB, Calibration) |
OSD Languages |
English, German, French, Italian, Japanese, Simplified Chinese, Spanish, Swedish, Traditional Chinese |
Others |
Color Adjustment (Brightness, Temperature, Gamma, Color Gamut, Hue, Saturation, Clipping, Gain, Independent 6-Color Control, Reset), Picture Expansion (Auto, Full Screen, Aspect Ratio, Dot by Dot), Input Color Format, Input Range, Noise Reduction, Auto Iuput Detection, Menu Rotation, Power Save, Indicator, Beep, Input Skip, Mode Skip, Custom Key, USB Selection, Signal Info, Monitor Info, Key Lock, DP Power Save, DUE Priority, Signal Format, Monitor Reset, I/P Conversion, YUV Color Matrix, Information Display |
Physical Specifications |
|
Dimensions (Landscape, W x H x D) |
638 x 404.1 - 559.1 x 265 mm |
Dimensions (Portrait, W x H x D) |
378.2 x 649 - 689 x 265 mm |
Dimensions (Without Stand, W x H x D) |
638 x 378.2 x 75 mm |
Net Weight |
10.1 kg |
Net Weight (Without Stand) |
6.5 kg |
Height Adjustment Range |
155 mm |
Tilt |
35° Up, 5° Down |
Swivel |
344° |
Pivot |
90° |
Hole Spacing (VESA Standard) |
100 x 100 mm |
Environmental Requirements |
|
Operating Temperature |
0 - 35 °C |
Operating Humidity (R.H., non condensing) |
20 - 80 % |
Certifications & Standards (Please contact EIZO for the latest information.) |
CB, CE, TUV/GS, cTUVus, FCC-B, CAN ICES-3 (B), TUV/S, PSE, VCCI-B, RCM, EAC, RoHS, WEEE, TUV/Ergonomics |
Dedicated Software |
|
Easy Screen-to-Print Color Matching Tool Quick Color Match |
Supported |
Proprietary Software |
|
Color Mangement Software ColorNavigator 7 |
Supported |
Supplied Accessories (May vary by country. Please contact EIZO for details.) |
|
Signal Cables |
USB Type-C (2 m), HDMI (2 m) |
Others |
AC power cord, USB cable, Setup guide, Warranty card |
