Eizo CS2740 27 inch 4K Monitor ColourEdge USB-C

115920

inc GST
Increase value Decrease value
Found a better price? We'll match it!* Price Match Now
  • Product Description
  • Specifications
  • What's in the Box?

The elegant 4K monitor for every creator.

With 4K UHD (3840 x 2160), a spacious 27-inch screen, and USB Type-C connectivity, this monitor facilitates a detail-oriented, comfortable, and streamlined workflow ideal for any creative field. Whether it be photography, video editing, or design, this monitor gives you everything you need to keep your imagination flowing.

A conventional monitor displays in Full HD with just 96 PPI. The ColorEdge CS2740 boasts a pixel density nearly twice that at an incredible 164 PPI for 4K image display that has never looked smoother. Alphanumeric characters and contours are distinguished with excellent sharpness so you can check even the finest details without needing to zoom in.

The ColorEdge CS2740 is the first CS series monitor to implement 4K UHD resolution (3840 x 2160), which is four times the size of Full HD. The remarkable detail ensures that high-resolution photos and other content are displayed crisply. The 27-inch screen provides ample space for easily displaying Full HD content in full with enough space to show toolbars, palettes, and other windows or applications simultaneously. This makes the monitor versatile for photos, video editing, design, and other types of creative work up to 4K.

The ColorEdge CS2740 features USB Type-C connectivity with 60 W power delivery. With a single USB Type-C cable, you can display video, transmit USB signals, and supply power to a connected device such as a smartphone or notebook PC. Simply plug in and get creative without worrying about additional cable clutter.

  • 27-inch wide-gamut LED with 3840 x 2160 pixels (4KHD) to deliver ultra-sharp details
  • EIZO microchip ensures precise, consistent, and lasting colour display
  • Wide gamut covering 99% of the Adobe RGB colour gamut
  • Precise hardware calibration of brightness, white balance, and gamma
  • Digital Uniformity Equalizer for top-rate luminance distribution and colour purity
  • Colour precision with 16bit look-up-table and up to 10bit colour reproduction
  • USB-C, DisplayPort, and HDMI ports
  • ColorNavigator calibration software included
  • Recommended optional accessories: measurement device for hardware calibration and monitor hood
Model Variations CS2740-BK
Panel
Type IPS
Backlight Wide-Gamut LED
Size 26.9" / 68.4 cm
Native Resolution 3840 x 2160 (16:9 aspect ratio)
Viewable Image Size (H x V) 596.2 x 335.3 mm
Pixel Pitch 0.155 x 0.155 mm
Pixel Density 164ppi
Display Colors 1.07 billion from a palette of 278 trillion
Viewing Angles (H / V, typical) 178°, 178°
Brightness (typical) 350 cd/m2
Contrast Ratio (typical) 1000:1
Response Time (typical) 10 ms (Gray-to-gray)
Color Gamut (typical) Adobe RGB: 99%
Video Signals
Input Terminals USB Type-C (DisplayPort Alt Mode, HDCP 1.3), DisplayPort (HDCP 1.3), HDMI (Deep Color, HDCP 2.2 / 1.4)
Digital Scanning Frequency (H / V) USB Type-C, DisplayPort: 25 - 137 kHz, 23 - 61 Hz
HDMI: 15 - 135 kHz, 23 - 61 Hz
USB
Upstream
USB 3.1 Gen 1: Type-C (DisplayPort Alt Mode, Power Delivery Source 60 W max.), USB 3.1 Gen 1: Type-B
Downstream USB 3.1 Gen 1: Type-A x 2
USB 2.0: Type-A x 2
Power
Power Requirements AC 100 - 240 V, 50 / 60 Hz
Typical Power Consumption
36 W
Maximum Power Consumption 168 W
Power Save Mode 1.0 W or less
Standby Mode 1.0 W or less
Features & Functions
Digital Uniformity Equalizer Yes
Preset Modes Color Mode (Custom, Adobe RGB, sRGB, Calibration)
OSD Languages English, German, French, Italian, Japanese, Simplified Chinese, Spanish, Swedish, Traditional Chinese
Others Color Adjustment, Input Color Format, YUV Color Matrix, Input Range, Noise Reduction, I/P Conversion, Picture Expansion, Menu Rotation, Power Save, Input Skip, Mode Skip, Custom Key, Information Display, Key Lock, DUE Priority
Physical Specifications
Dimensions (Landscape, W x H x D)
638 x 404.1 - 559.1 x 265 mm
Dimensions (Portrait, W x H x D)
378.2 x 649 - 689 x 265 mm
Dimensions (Without Stand, W x H x D)
638 x 378.2 x 75 mm
Net Weight
10.3 kg
Net Weight (Without Stand) 6.7 kg
Height Adjustment Range 155 mm
Tilt 35° Up, 5° Down
Swivel 344°
Pivot 90°
Hole Spacing (VESA Standard) 100 x 100 mm
Environmental Requirements
Operating Temperature 0 - 35 °C
Operating Humidity (R.H., non condensing) 20 - 80 %
Certifications & Standards (Please contact EIZO for the latest information.) CB, CE, TUV/GS, cTUVus, FCC-B, CAN ICES-3 (B), TUV/S, PSE, VCCI-B, RCM, EAC, RoHS, WEEE, TUV/Ergonomics
Dedicated Software
Easy Screen-to-Print Color Matching Tool Quick Color Match Supported
Proprietary Software
Color Mangement Software ColorNavigator 7 Supported
Color Mangement Software ColorNavigator 6 Supported
Supplied Accessories (May vary by country. Please contact EIZO for details.)
Signal Cables
USB Type-C (2 m), DisplayPort (2 m)
Others AC power cord, USB cable, Setup guide, Warranty card
  • EIZO ColorEdge CS2740 26.9" 16:9 Wide Gamut 4K IPS Monitor
  • 4 x Screw
  • DisplayPort Cable (6.6' / 2.0m)
  • USB Type-C Cable (6.6' / 2.0m)
  • USB Type-B to Type-A Cable
  • AC Power Cord
