| Max Print Width |
17 inch (432 mm) |
| Max Sheet Size |
A2+ |
| Printhead |
Epson Micro Piezo |
| Print Modes |
Uni & Bi-directional |
| Features |
Variable Sized Droplet Technology (VSDT) |
| Advanced Epson LUT |
| Enhanced Colour Density and Gamut |
| Enhanced Print Durability |
| Black Enhance Overcoat |
| Nozzle Configuration |
180 per colour |
| Active Channels |
10 (Dedicated Pk / Mk ink lines) |
| Max Resolution |
5760 x 1440 dpi |
| Min Droplet Size |
1.5 pl |
| Family |
UltraChrome Pro10 |
| Type |
Aqueous all-pigment |
| Cartridge Size |
200 ml |
| Format |
Cut sheet and Roll |
| Size |
8" x 10" (203 x 254 mm) - A2+ (432 x 610 mm) sheets |
| 203-432 mm wide x 150 mm diameter 3" core / 103 mm diameter 2" core rolls |
| Thickness |
0.08-1.5 mm sheets |
| 0.08-0.5 mm rolls |
| Min Margins (Normal Printing) |
Sheets – 3 mm top, 0 mm left and right, 3-14 mm bottom |
| Roll – 3 mm top and bottom, 0 mm left and right |
| Borderless Printing (Supported on nominated widths only) |
Roll media: 8" (203.2 mm)*, 10" (254 mm), 11" (279.4 mm)*, 14" (355.6 mm), 16" (406.4 mm), 420 mm*, 17" (431.8 mm), A4/A3/A3+/A2, 300 mm |
| Cut sheets / Poster board: 10" (254 mm), 14" (355.6 mm), 16" (406.4 mm), 17" (431.8 mm), A4/A3/A3+, 300 mm |
| |
| * Requires a 2" core and use of the borderless print spacer supplied with the printer |
| Max Print Length |
18 m |
| Loading |
Front and rear manual, top tray and front cassette (up to 250 plain and 100 photo) sheets |
| Top roll (spindle style with dual tension settings) |
| Roll Handling |
Heavy-duty rotary auto-cutter (under 5s per page) |
| Media Barcode System for roll management |
| Output |
Front with extendable tray |
| Double Sided Printing |
Supported via manual loading however please refer to the user guide and contact Epson or your authorised dealer before selecting any media for this purpose in order to check suitability. |
| Control Panel |
4.3" Touchscreen Colour LCD |
| Interface |
High Speed USB 3.0 |
| Ethernet 10Base-T / 100Base-TX, Wi-Fi, Wi-Fi Direct |
| Web Downloads (Windows) |
Printer Driver, EpsonNet Print, EpsonNet Setup Manager, Epson Print Layout, Epson Edge Dashboard, Epson ColorBase3, Epson Media Installer, Epson Device Admin, Device Status System (DSS), Epson SureLab OrderController, Software and Firmware Updater, Epson Cloud Solution PORT |
| Web Downloads (Mac) |
Printer Driver, Firmware Updater, EpsonNet Config SE, Epson Manual Launcher, Epson Print Layout, Epson Edge Dashboard, Epson Media Installer, Epson ColorBase3iOS, Epson Cloud Solution PORT |
| OS Compatibility |
Mac OS X 10.9.5 or later |
| Windows 11, 10, 8/8.1, 7 |
| Third-party Software Compatibility |
Compatible with a wide range of design, production, workflow management, and RIP software |
| Memory |
1 GB |
| Language |
ESC/P Raster |
| Operational Temp |
10° to 35° C (15-25° C recommended) |
| Operational Humidity |
20 to 80% with no condensation (40-60% recommended) |
| Power Supply |
100 - 240 V, 50 Hz - 60 Hz AC, 2 A |
| Power Consumption |
42 W Operating / Standby 17 W / 2.4 W Sleep |
| Operating Noise |
46 dB |
| Operational Space |
1163 x 1349 x 586 mm recommended |
