Model name |
|
|
FUJIFILM GFX100 II |
Lens Mount |
|
|
FUJIFILM G mount |
Image sensor |
|
|
43.8mm×32.9mm Bayer array with primary color filter |
Number of effective pixels |
|
|
102 million pixels |
Sensor Cleaning System |
|
|
Ultra Sonic Vibration |
Image Processing Engine |
|
|
X-Processor 5 |
Storage media |
|
|
SD Card (-2GB) |
|
|
|
SDHC Card (-32GB) |
|
|
|
SDXC Card (-2TB) |
|
|
|
UHS-I |
|
|
|
UHS-II |
|
|
|
Video Speed Class V90 |
|
|
|
CFexpress Type B Card (-2TB) |
|
|
|
SSD (-2TB) |
|
|
|
*Please see the Fujifilm website (https://fujifilm-x.com/support/compatibility/cameras/) to check memory card compatibility. |
File format of still image |
DCF |
|
Compliant with Design rule for Camera File system (DCF2.0) |
|
JPEG |
|
Exif Ver.2.32 |
|
HEIF |
|
4:2:2 10bit |
|
RAW |
|
14bit / 16bit RAW (RAF original format) |
|
TIFF |
|
8bit / 16bit RGB (In-camera Raw Conversion Only) |
|
|
|
*Exif 2.32 is a digital camera file format that contains a variety of shooting information for optimal printing |
Number of recorded pixels |
[L] |
4:3 |
11648 x 8736 |
|
|
3:2 |
11648 x 7768 |
|
|
16:9 |
11648 x 6552 |
|
|
1:1 |
8736 x 8736 |
|
|
65:24 |
11648 x 4304 |
|
|
5:4 |
10928 x 8736 |
|
|
7:6 |
10192 x 8736 |
|
[M] |
4:3 |
8256 x 6192 |
|
|
3:2 |
8256 x 5504 |
|
|
16:9 |
8256 x 4640 |
|
|
1:1 |
6192 x 6192 |
|
|
65:24 |
8256 x 3048 |
|
|
5:4 |
7744 x 6192 |
|
|
7:6 |
7232 x 6192 |
|
[S] |
4:3 |
4000 x 3000 |
|
|
3:2 |
4000 x 2664 |
|
|
16:9 |
4000 x 2248 |
|
|
1:1 |
2992 x 2992 |
|
|
65:24 |
4000 x 1480 |
|
|
5:4 |
3744 x 3000 |
|
|
7:6 |
3504 x 3000 |
Panorama |
[L] |
vertical |
|
|
|
Horizontal |
|
|
[M] |
Vertical |
|
|
|
Horizontal |
|
Lens |
Type |
|
|
|
Focal length |
|
|
|
Max. aperture |
|
|
|
Lens configuration |
|
|
|
ND filter |
|
|
Aperture |
|
|
|
Focus range |
|
|
|
Conversion lens |
|
|
|
|
|
|
|
|
|
|
|
Digital Tele-Converter |
|
|
|
|
|
|
|
|
|
|
|
Sensitivity |
Still Image |
Standard Output |
AUTO1 |
|
|
|
AUTO2 |
|
|
|
AUTO3 |
|
|
|
ISO80~12800 (1/3 step) |
|
|
Extended Output |
ISO40 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
ISO25600 |
|
|
|
ISO51200 |
|
|
|
ISO102400 |
|
Movie |
Standard Output |
AUTO |
|
|
|
ISO100~12800 (1/3 step) |
|
|
Extended Output |
ISO25600 |
Exposure control |
|
|
TTL 256-zone metering |
|
|
|
Multi |
|
|
|
Spot |
|
|
|
Average |
|
|
|
Center Weighted |
Exposure mode |
|
|
P (Program AE) |
|
|
|
A (Aperture Priority AE) |
|
|
|
S (Shutter Speed Priority AE) |
|
|
|
M (Manual Exposure) |
Exposure compensation |
Still |
|
-5.0EV~+5.0EV 1/3EV step |
|
Movie |
|
-2.0EV~+2.0EV 1/3EV step |
Image stabilizer |
Mechanism |
|
Image sensor shift mechanism with 5-axis compensation |
|
Compensation Effect |
|
8.0 stops |
|
|
|
*based on CIPA standard |
|
|
|
*Pitch/yaw shake only |
|
|
|
*With GF63mmF2.8 R WR lens mounted |
|
Digital Image Stabilization |
|
Yes (movie mode only) |
|
IS MODE BOOST |
|
Yes (movie mode only) |
Shutter type |
|
|
Focal Plane Shutter |
Shutter speed |
Mechanical shutter |
P mode |
30sec. to 1/4000sec. |
|
|
A mode |
30sec. to 1/4000sec. |
|
|
S/M mode |
60min. to 1/4000sec. |
|
|
Bulb |
up to 60min. |
|
Electronic shutter |
P mode |
30sec. to 1/32000sec. |
|
|
A mode |
30sec. to 1/32000sec. |
|
|
S/M mode |
60min. to 1/32000sec. |
|
|
Bulb |
up to 60min. |
|
|
|
*The Electronic Shutter may not be suitable for fast-moving objects or handheld shooting. Flash can not be used. |
|
Electronic front curtain shutter |
P mode |
|
|
|
A mode |
|
|
|
S/M mode |
|
|
|
Bulb |
|
|
Mechanical + Electronic shutter |
P mode |
30sec. to 1/32000sec. |
|
|
A mode |
30sec. to 1/32000sec. |
|
|
S/M mode |
60min. to 1/32000sec. |
|
|
Bulb |
up to 60min. |
|
|
|
*Mechanical shutter works until 1/4000sec. |
|
|
|
*The Electronic Shutter may not be suitable for fast-moving objects or handheld shooting. Flash can not be used. |
|
E-front + Mechanical shutter |
P mode |
30sec. to 1/4000sec. |
|
(GFX: Electronic Front Curtain Shutter) |
A mode |
30sec. to 1/4000sec. |
|
|
S/M mode |
60min. to 1/4000sec. |
|
|
Bulb |
up to 60min. |
|
|
|
*Electronic front curtain shutter works until 1/1250sec. |
|
|
|
*When using the electronic front curtain shutter, the continuous shooting supports CL only |
|
E-front + Mechanical + Electronic shutter |
P mode |
30sec. to 1/32000sec. |
|
(GFX: E-Front + Electronic Shutter) |
A mode |
30sec. to 1/32000sec. |
|
|
S/M mode |
60min. to 1/32000sec. |
|
|
Bulb |
up to 60min. |
|
|
|
*Electronic front curtain shutter works until 1/1250sec, Mechanical shutter works until 1/4000sec. |
|
|
|
*The Electronic Shutter may not be suitable for fast-moving objects or handheld shooting. Flash can not be used. |
|
|
|
*When using the electronic front curtain shutter, the continuous shooting supports CL only |
|
Movie |
8K/DCI8K |
1/4000sec. to 1/24 sec. |
|
|
6.2K |
|
|
|
5.8K |
1/4000sec. to 1/24 sec. |
|
|
5.4K |
1/4000sec. to 1/24 sec. |
|
|
4.8K |
1/4000sec. to 1/24 sec. |
|
|
4.6K(ANAMOR) |
1/4000sec. to 1/24 sec. |
|
|
4K/DCI4K |
1/4000sec. to 1/8 sec. |
|
|
FHD |
1/4000sec. to 1/8 sec. |
|
|
|
*Cannot choose slower shutter speed than framerate for some settings. |
|
Synchronized shutter speed for flash |
Mechanical shutter |
1/125sec. or slower |
|
|
Electronic shutter |
|
Continuous shooting |
CH |
Electronic shutter |
Approx. 8.7fps (35mm Format Mode ON) |
|
No. of recordable frames |
JPEG |
1000+ frames |
|
|
Compressed RAW |
1000+ frames |
|
|
Lossless compressed RAW |
1000+ frames |
|
|
Uncompressed RAW |
1000+ frames |
|
|
Compressed RAW + JPEG |
156 frames |
|
|
Lossless compressed RAW + JPEG |
148 frames |
|
|
Uncompressed RAW + JPEG |
71 frames |
|
CH |
Electronic shutter |
Approx. 5.8fps (35mm Format Mode ON) |
|
No. of recordable frames |
JPEG |
1000+ frames |
|
|
Compressed RAW |
1000+ frames |
|
|
Lossless compressed RAW |
1000+ frames |
|
|
Uncompressed RAW |
1000+ frames |
|
|
Compressed RAW + JPEG |
1000+ frames |
|
|
Lossless compressed RAW + JPEG |
1000+ frames |
|
|
Uncompressed RAW + JPEG |
1000+ frames |
|
CH |
Electronic shutter |
|
|
No. of recordable frames |
JPEG |
|
|
|
Compressed RAW |
|
|
|
Lossless compressed RAW |
|
|
|
Uncompressed RAW |
|
|
|
Compressed RAW + JPEG |
|
|
|
Lossless compressed RAW + JPEG |
|
|
|
Uncompressed RAW + JPEG |
|
Continuous shooting |
CH |
Electronic shutter |
Approx. 5.3fps |
|
No. of recordable frames |
JPEG |
1000+ frames |
|
|
Compressed RAW |
1000+ frames |
|
|
Lossless compressed RAW |
1000+ frames |
|
|
Uncompressed RAW |
390 frames |
|
|
Compressed RAW+JPEG |
119 frames |
|
|
Lossless compressed RAW+JPEG |
119 frames |
|
|
Uncompressed RAW+JPEG |
98 frames |
|
CH |
Electronic shutter |
|
|
No. of recordable frames |
JPEG |
|
|
|
Compressed RAW |
|
|
|
Lossless compressed RAW |
|
|
|
Uncompressed RAW |
|
|
|
Compressed RAW+JPEG |
|
|
|
Lossless compressed RAW+JPEG |
|
|
|
Uncompressed RAW+JPEG |
|
|
CH |
Electronic shutter |
|
|
No. of recordable frames |
JPEG |
|
|
|
Compressed RAW |
|
|
|
Lossless compressed RAW |
|
|
|
Uncompressed RAW |
|
|
|
Compressed RAW+JPEG |
|
|
|
Lossless compressed RAW+JPEG |
|
|
|
Uncompressed RAW+JPEG |
|
|
CH |
Electronic shutter |
|
|
No. of recordable frames |
JPEG |
|
|
|
Compressed RAW |
|
|
|
Lossless compressed RAW |
|
|
|
Uncompressed RAW |
|
|
|
Compressed RAW+JPEG |
|
|
|
Lossless compressed RAW+JPEG |
|
|
|
Uncompressed RAW+JPEG |
|
|
CH |
Electronic Front Curtain Shutter |
|
|
No. of recordable frames |
JPEG |
|
|
|
Compressed RAW |
|
|
|
Lossless compressed RAW |
|
|
|
Uncompressed RAW |
|
|
CH |
Mechanical shutter |
Approx. 8.0fps |
|
No. of recordable frames |
JPEG |
1000+ frames |
|
|
Compressed RAW |
325 frames |
|
|
Lossless compressed RAW |
302 frames |
|
|
Uncompressed RAW |
76 frames |
|
|
Compressed RAW+JPEG |
75 frames |
|
|
Lossless compressed RAW+JPEG |
75 frames |
|
|
Uncompressed RAW+JPEG |
55 frames |
|
CH |
Mechanical shutter |
Approx. 5.0fps |
|
No. of recordable frames |
JPEG |
1000+ frames |
|
|
Compressed RAW |
1000+ frames |
|
|
Lossless compressed RAW |
1000+ frames |
|
|
Uncompressed RAW |
497 frames |
|
|
Compressed RAW+JPEG |
153 frames |
|
|
Lossless compressed RAW+JPEG |
152 frames |
|
|
Uncompressed RAW+JPEG |
116 frames |
|
CL |
Mechanical shutter |
Approx. 2.0fps |
|
No. of recordable frames |
JPEG |
1000+ frames |
|
|
Compressed RAW |
1000+ frames |
|
|
Lossless compressed RAW |
1000+ frames |
|
|
Uncompressed RAW |
1000+ frames |
|
|
Compressed RAW+JPEG |
1000+ frames |
|
|
Lossless compressed RAW+JPEG |
1000+ frames |
|
|
Uncompressed RAW+JPEG |
1000+ frames |
|
CL |
|
|
|
No. of recordable frames |
JPEG |
|
|
|
Compressed RAW |
|
|
|
Lossless compressed RAW |
|
|
|
Uncompressed RAW |
|
|
CL |
|
|
|
No. of recordable frames |
JPEG |
|
|
|
Compressed RAW |
|
|
|
Lossless compressed RAW |
|
|
|
Uncompressed RAW |
|
|
CL |
|
|
|
No. of recordable frames |
JPEG |
|
|
|
Compressed RAW |
|
|
|
Lossless compressed RAW |
|
|
|
Uncompressed RAW |
|
|
Pre-shot |
Electronic shutter, 1.25 x Crop |
|
|
No. of recordable frames |
While half press |
|
|
|
After full press |
|
|
|
Total |
|
|
Pre-shot |
Electronic shutter, 1.25 x Crop |
|
|
No. of recordable frames |
While half press |
|
|
|
After full press |
|
|
|
Total |
|
|
Pre-shot |
Electronic shutter, 1.25 x Crop |
|
|
No. of recordable frames |
While half press |
|
|
|
After full press |
|
|
|
Total |
|
|
Pre-shot |
Electronic shutter |
|
|
No. of recordable frames |
While half press |
|
|
|
After full press |
|
|
|
Total |
|
|
Pre-shot |
Electronic shutter |
|
|
No. of recordable frames |
While half press |
|
|
|
After full press |
|
|
|
Total |
|
|
Pre-shot |
Electronic shutter |
|
|
No. of recordable frames |
While half press |
|
|
|
After full press |
|
|
|
Total |
|
|
Pre-shot |
Electronic shutter |
|
|
No. of recordable frames |
While half press |
|
|
|
After full press |
|
|
|
Total |
|
|
|
|
*Electronic Front Curtain Shutter support CL only. |
|
|
|
*No. of recordable frames are calculated based on CFexpress Type B card in a cold start |
|
|
|
*Recordable frames depends on recording media |
|
|
|
*Speed of continuous shooting depends on shooting environment and shooting frames |
Drive Mode |
AE Bracketing |
|
2 frames |
|
|
|
3 frames |
|
|
|
5 frames |
|
|
|
7 frames |
|
|
|
9 frames |
|
|
|
*by 1/3EV step, up to ±3EV steps |
|
Filmsimulation bracketing |
|
Any 3 types of film simulation selectable |
|
Dynamic Range Bracketing |
|
100% |
|
|
|
200% |
|
|
|
400% |
|
ISO sensitivity Bracketing |
|
±1/3EV |
|
|
|
±2/3EV |
|
|
|
±1EV |
|
White Balance Bracketing |
|
±1 |
|
|
|
±2 |
|
|
|
±3 |
|
Focus Bracketing |
|
AUTO |
|
|
|
MANUAL |
|
Multiple Exposure |
|
Yes (Max. 9 frames) |
|
|
|
Additive |
|
|
|
Average |
|
|
|
Bright |
|
|
|
Dark |
|
HDR Mode |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Advanced filter |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Pixel Shift Multi Shot |
HIGH RESOLUTION + ACCURATE COLOR |
Yes |
|
|
ACCURATE COLOR |
Yes |
Focus |
Mode |
|
Single AF |
|
|
|
Continuous AF |
|
|
|
MF |
|
Type |
|
Intelligent Hybrid AF (TTL contrast AF / TTL phase detection AF) |
|
Low-light Performance |
Contrast |
-2.5EV |
|
|
|
|
|
|
|
GF80mmF1.7 attached |
|
|
Phase Detection |
-5.5EV |
|
|
|
GF80mmF1.7 attached |
|
AF frame selection |
Single point AF |
13x9 / 25x17 (Changeable size of AF frame) |
|
|
Zone AF |
3x3 / 5x5 / 7x7 / Custom1-3 from 117 areas on 13×9 grid |
|
|
Wide/Tracking AF |
Yes (AF-S: Wide / AF-C: Tracking) |
|
|
All |
Yes |
|
Face/eye detection |
|
Yes |
|
Subject detection |
|
Yes (Animal/Bird/Automobile/Motorcycle&Bike/Airplane/Train) |
Flash |
Built-in flash |
|
|
|
|
Guide Number |
|
|
|
Effective range(ISO1600) |
|
|
|
Sync. Mode |
|
|
|
|
|
|
|
Flash Mode |
|
|
|
|
|
|
|
|
|
|
|
|
|
Flash |
EF-X8 |
Guide Number |
|
|
|
Sync. Mode |
|
|
|
|
|
|
|
Flash Mode |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Shoe mount flash |
Sync. Mode |
1st Curtain |
|
|
|
2nd Curtain |
|
|
|
AUTO FP (HSS) |
|
|
Flash Mode |
TTL (TTL AUTO / STANDARD / SLOW SYNC. ) |
|
|
|
MANUAL |
|
|
|
MULTI *When EF-X500 is set |
|
|
|
OFF |
|
Synchronized terminal |
Sync. Mode |
1st Curtain |
|
|
|
2nd Curtain |
|
|
Flash Mode |
MANUAL |
Hot shoe |
|
|
Yes (Dedicated TTL Flash compatible) |
Viewfinder (Hybrid viewfinder) |
OVF |
|
|
|
|
Coverage of Frame Area v.s. Capturing Area |
|
|
|
Magnification |
|
Viewfinder |
EVF |
|
0.64 inch OLED Color Viewfinder |
|
|
|
Approx. 9.44 million dots |
|
|
Coverage of Viewing Area vs. Capturing Area |
Approx. 100% |
|
|
Eyepoint |
Approx. 21mm (from the Rear End of the Camera's Eyepiece) |
|
|
Diopter Adjustment |
-5~+2m-1 |
|
|
Magnification |
1.00x with 50mm Lens (35mm Equivalent) at infinity and Diopter set to -1.0m-1 |
|
|
Diagonal Angle of View |
approx. 47° (Horizontal angle of view: approx. 38° ) |
|
|
|
Built-In Eye Sensor |
LCD monitor |
|
|
3.2 inch Tilt-Type(Three Direction) Touch Screen Color LCD Monitor |
|
Aspect Ratio |
|
4:3 |
|
Dots |
|
Approx. 2.36 million dots |
Touch Screen Mode |
Shooting Mode |
|
|
|
|
|
AF |
|
|
|
Focus Area |
|
|
|
OFF |
|
|
|
Double Tap Setting (ON/OFF) |
|
|
|
Touch Function Setting (ON/OFF) |
|
|
|
|
|
|
|
EVF Touch Screen Area Setting |
|
|
|
|
|
Playback Mode |
|
Swipe |
|
|
|
Pinch-in / Pinch-out |
|
|
|
Double-tap |
|
|
|
Drag |
Sub LCD monitor |
|
|
2.09 inch Monochrome LCD Monitor |
|
Aspect Ratio |
|
4:3 |
|
Dots |
|
320x219-dot |
Rear sub monitor |
|
|
|
|
Aspect Ratio |
|
|
|
Dots |
|
|
Movie recording |
File format |
MOV |
Apple ProRes 422 HQ, Linear PCM (Stereo sound 24bit / 48KHz sampling) |
|
|
|
Apple ProRes 422, Linear PCM (Stereo sound 24bit / 48KHz sampling) |
|
|
|
Apple ProRes 422 LT, Linear PCM (Stereo sound 24bit / 48KHz sampling) |
|
|
|
HEVC/H.265, Linear PCM (Stereo sound 24bit / 48KHz sampling) |
|
|
|
MPEG-4 AVC/H.264, Linear PCM (Stereo sound 24bit / 48KHz sampling) |
|
|
MP4 |
MPEG-4 AVC/H.264, AAC |
|
Movie compression |
|
All Intra |
|
|
|
Long GOP |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
8K(17:9) |
File size |
8192 x 4320 |
|
|
Frame rate |
24p |
|
|
|
23.98p |
|
|
Bitrate |
720Mbps |
|
|
|
360Mbps |
|
|
|
200Mbps |
|
|
|
100Mbps |
|
|
|
50Mbps |
|
8K(16:9) |
File size |
7680 x 4320 |
|
|
Frame rate |
29.97p |
|
|
|
25p |
|
|
|
24p |
|
|
|
23.98p |
|
|
Bitrate |
720Mbps |
|
|
|
360Mbps |
|
|
|
200Mbps |
|
|
|
100Mbps |
|
|
|
50Mbps |
|
8K(2.76:1) |
File size |
8192 x 2968 |
|
|
Frame rate |
24p |
|
|
|
23.98p |
|
|
Bitrate |
720Mbps |
|
|
|
360Mbps |
|
|
|
200Mbps |
|
|
|
100Mbps |
|
|
|
50Mbps |
|
6.2K(3:2) |
File size |
|
|
|
Frame rate |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Bitrate |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
6.2K(16:9) |
File size |
|
|
|
Frame rate |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Bitrate |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
5.8K(2.35:1) |
File size |
5824 x 2476 |
|
|
Frame rate |
29.97p |
|
|
|
25p |
|
|
|
24p |
|
|
|
23.98p |
|
|
Bitrate |
720Mbps |
|
|
|
360Mbps |
|
|
|
200Mbps |
|
|
|
100Mbps |
|
|
|
50Mbps |
|
5.4K(17:9) |
File size |
5440 x 2868 |
|
|
Frame rate |
29.97p |
|
|
|
25p |
|
|
|
24p |
|
|
|
23.98p |
|
|
Bitrate |
720Mbps |
|
|
|
360Mbps |
|
|
|
200Mbps |
|
|
|
100Mbps |
|
|
|
50Mbps |
|
4.8K(3:2) |
File size |
4776 x 3184 |
|
|
Frame rate |
24p |
|
|
|
23.98p |
|
|
Bitrate |
720Mbps |
|
|
|
360Mbps |
|
|
|
200Mbps |
|
|
|
100Mbps |
|
|
|
50Mbps |
|
4.8K(16:9) |
File size |
4776 x 2688 |
|
|
Frame rate |
29.97p |
|
|
|
25p |
|
|
|
24p |
|
|
|
23.98p |
|
|
Bitrate |
720Mbps |
|
|
|
360Mbps |
|
|
|
200Mbps |
|
|
|
100Mbps |
|
|
|
50Mbps |
|
4.6K(1.38:1) |
File size |
4664 x 3380 |
|
|
Frame rate |
24p |
|
|
|
23.98p |
|
|
Bitrate |
720Mbps |
|
|
|
360Mbps |
|
|
|
200Mbps |
|
|
|
100Mbps |
|
|
|
50Mbps |
|
DCI4K HQ(17:9) |
File size |
|
|
|
Frame rate |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Bitrate |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
4K HQ(16:9) |
File size |
|
|
|
Frame rate |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Bitrate |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
DCI4K(17:9) |
File size |
4096 x 2160 |
|
|
Frame rate |
59.94p |
|
|
|
50p |
|
|
|
29.97p |
|
|
|
25p |
|
|
|
24p |
|
|
|
23.98p |
|
|
Bitrate |
720Mbps |
|
|
|
|
|
|
|
360Mbps |
|
|
|
200Mbps |
|
|
|
100Mbps |
|
|
|
50Mbps |
|
|
Recording time |
|
|
|
|
|
|
4K(16:9) |
File size |
3840 x 2160 |
|
|
Frame rate |
59.94p |
|
|
|
50p |
|
|
|
29.97p |
|
|
|
25p |
|
|
|
24p |
|
|
|
23.98p |
|
|
Bitrate |
720Mbps |
|
|
|
|
|
|
|
360Mbps |
|
|
|
200Mbps |
|
|
|
100Mbps |
|
|
|
50Mbps |
|
|
Recording time |
|
|
|
|
|
|
Full HD(17:9) |
File size |
2048 x 1080 |
|
|
Frame rate |
59.94p |
|
|
|
50p |
|
|
|
29.97p |
|
|
|
25p |
|
|
|
24p |
|
|
|
23.98p |
|
|
Bitrate |
720Mbps |
|
|
|
360Mbps |
|
|
|
200Mbps |
|
|
|
100Mbps |
|
|
|
50Mbps |
|
|
Recording time |
|
|
Full HD(16:9) |
File size |
1920 x 1080 |
|
|
Frame rate |
59.94p |
|
|
|
50p |
|
|
|
29.97p |
|
|
|
25p |
|
|
|
24p |
|
|
|
23.98p |
|
|
Bitrate |
720Mbps |
|
|
|
360Mbps |
|
|
|
200Mbps |
|
|
|
100Mbps |
|
|
|
50Mbps |
|
|
|
|
|
|
Recording time |
|
|
Full HD LP(17:9) |
File size |
|
|
|
Frame rate |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Bitrate |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Recording time |
|
|
Full HDLP(16:9) |
File size |
|
|
|
Frame rate |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Bitrate |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Recording time |
|
|
DCI4K(17:9) High speed rec. |
File size |
|
|
|
Frame rate |
|
|
|
|
|
|
|
Bitrate |
|
|
|
|
|
|
|
|
|
|
|
Recording time |
|
|
|
|
|
|
4K(16:9) High speed rec. |
File size |
|
|
|
Frame rate |
|
|
|
|
|
|
|
Bitrate |
|
|
|
|
|
|
|
|
|
|
|
Recording time |
|
|
|
|
|
|
Full HD(17:9) High speed rec. |
File size |
2048 x 1080 |
|
|
Frame rate |
|
|
|
|
|
|
|
|
120p |
|
|
|
100p |
|
|
Bitrate |
720Mbps (recording) |
|
|
|
360Mbps (recording) |
|
|
|
200Mbps (recording) |
|
|
Recording time |
|
|
|
|
|
|
Full HD(16:9) High speed rec. |
File size |
1920 x 1080 |
|
|
Frame rate |
|
|
|
|
|
|
|
|
120p |
|
|
|
100p |
|
|
Bitrate |
720Mbps (recording) |
|
|
|
360Mbps (recording) |
|
|
|
200Mbps (recording) |
|
|
Recording time |
|
|
|
|
|
|
HD(16:9) |
File size |
|
|
|
Frame rate |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Bitrate |
|
|
|
Recording time |
|
|
|
|
*Selectable mode will be changed depending on the "Image Format" setting. |
|
|
|
*For recording movies, use a CFexpress Type B card or SD memory card with UHS Speed Class 3 or higher. |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
*For recording movies in 360Mbps, use a CFexpress Type B card or SD memory card with Video Speed Class 60 or higher. |
|
|
|
*For recording movies in 720Mbps, use a CFexpress Type B card or SD memory card with Video Speed Class 90 or higher. |
|
|
|
|
|
|
|
|
|
|
|
*Selectable bitrate will be changed depends on the setting. |
|
|
|
*Apple ProRes codec can be only recorded to CFexpress Type B card |
|
|
|
*Bitrate for Apple ProRes codec is not selectable. |
|
|
|
*Recording time can become short depending on the temperature and/or shooting conditions |
Scene Position mode |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Film simulation mode |
|
|
20 modes |
|
|
|
PROVIA/Standard |
|
|
|
Velvia/Vivid |
|
|
|
ASTIA/Soft |
|
|
|
Classic Chrome |
|
|
|
REALA ACE |
|
|
|
PRO Neg.Hi |
|
|
|
PRO Neg.Std |
|
|
|
Classic Neg. |
|
|
|
Nostalgic Neg. |
|
|
|
ETERNA/Cinema |
|
|
|
ETERNA BLEACH BYPASS |
|
|
|
ACROS |
|
|
|
ACROS + Ye Filter |
|
|
|
ACROS + R Filter |
|
|
|
ACROS + G Filter |
|
|
|
Black & White |
|
|
|
Black & White + Ye Filter |
|
|
|
Black & White + R Filter |
|
|
|
Black & White + G Filter |
|
|
|
Sepia |
Monochromatic Color |
|
|
Yes |
B & W ADJ. (Warm/Cool) |
|
|
|
Grain Effect |
Roughness |
|
STRONG, WEAK, OFF |
|
Size |
|
LARGE, SMALL |
Color Chrome Effect |
|
|
STRONG, WEAK, OFF |
Color chrome Blue |
|
|
STRONG, WEAK, OFF |
Smooth Skin Effect |
|
|
STRONG, WEAK, OFF |
Dynamic range setting |
Still |
|
AUTO / 100% / 200% / 400% |
|
|
ISO restriction |
DR100%: No limit、DR200%: ISO160 or more、DR400%: ISO320 or more |
|
Movie |
|
100% / 200% / 400% |
|
|
ISO restriction |
DR100%: No limit、DR200%: ISO200 or more、DR400%: ISO400 or more |
White balance |
Auto |
|
White Priority |
|
|
|
Auto |
|
|
|
Ambience Priority |
|
Custom |
|
Custom1 - 3 |
|
Color temperature selection |
|
2500K~10000K |
|
Preset |
|
Daylight |
|
|
|
Shade |
|
|
|
Fluorescent Light-1 |
|
|
|
Fluorescent Light-2 |
|
|
|
Fluorescent Light-3 |
|
|
|
Incandescent Light |
|
|
|
Underwater |
Clarity setting |
|
|
±5 steps |
Self-timer |
Still |
|
10sec. |
|
|
|
2sec. |
|
Movie |
|
10sec. |
|
|
|
5sec. |
|
|
|
3sec. |
Interval timer shooting |
|
|
Yes (Setting : Interval, Number of shots, Starting time, Interval timer shooting exposure smoothing, Interval priority mode) |
Wireless transmitter |
Standard |
|
IEEE802.11a/b/g/n/ac (standard wireless protocol) |
|
Encryption |
|
WPA/WPA2 mixed mode, WPA3 |
|
Access mode |
|
Infrastructure |
Bluetooth® |
Standartd |
|
Bluetooth Ver. 4.2 (Bluetooth low energy) |
|
Operating frequency (Center frequency) |
2402〜2480MHz |
Terminal |
Digital interface |
|
USB Type-C (USB3.2 Gen2x1) |
|
HDMI output |
|
HDMI connector (Type A) |
|
LAN Terminal |
|
1000BASE-T、100BASE-TX、10BASE-T |
|
Others |
|
ø3.5mm, stereo mini connector (Microphone) |
|
|
|
ø3.5mm, stereo mini connector (Headphone) |
|
|
|
ø2.5mm, Remote Release Connector |
|
|
|
|
|
|
|
Hot shoe |
|
|
|
Synchronized terninal |
Power supply |
|
|
NP-W235 Li-ion battery (included) |
|
Battery life for still images |
Economy Mode |
|
|
|
Normal Mode |
Approx. 540 frames |
|
|
|
|
|
|
|
*Auto power save ON |
|
|
|
*When GF63mmF2.8 R WR is set |
|
Actual battery life of movie capture |
8K |
Approx. 60min. (29.97p) |
|
|
6.2K |
|
|
|
4K |
Approx. 60min. (59.94p) |
|
|
Full HD |
Approx. 80min. (59.94p) |
|
|
|
|
|
|
|
*Face detection is set to OFF |
|
Continuance battery life of movie capture |
8K |
Approx. 80min. (29.97p) |
|
|
6.2K |
|
|
|
4K |
Approx. 90min. (59.94p) |
|
|
Full HD |
Approx. 140min. (59.94p) |
|
|
|
|
|
|
|
*Face detection is set to OFF |
|
|
|
*Approximate number of frames or movie recording time that can be taken with a fully-charged based on CIPA Standard. |
Dimensions |
|
Width |
152.4mm |
|
|
Height |
117.4mm |
|
|
Depth |
98.6mm |
|
|
(Minimum Depth) |
46.5mm |
|
Excluding EVF |
Width |
152.4mm |
|
|
Height |
103.5mm |
|
|
Depth |
73.5mm |
|
|
(Minimum Depth) |
46.5mm |
Weight |
including battery and memory card |
948g (including EVF: 1,030g) |
|
excluding battery and memory card |
867g (including EVF: 949g) |
Operation Environment |
Operating Temperature |
|
-10℃~+40℃ |
|
Operating Humidity |
|
10% - 80% (no condensation) |
