Imaging
Lens Mount FUJIFILM X
Sensor Resolution Effective: 40.2 Megapixel
Sensor Type 23.5 x 15.6 mm (APS-C) CMOS
Crop Factor 1.5x
Image Stabilization Sensor-Shift, 5-Axis
Capture Type Stills & Video
Exposure Control
Shutter Type Electronic Shutter, Mechanical Focal Plane Shutter
Shutter Speed Mechanical Shutter
1/8000 to 30 Seconds in Program Mode
1/8000 to 30 Seconds in Aperture Priority Mode
1/8000 to 15 Minutes in Shutter Priority Mode
1/8000 to 15 Minutes in Manual Mode
Up to 60 Minutes in Bulb Mode
Electronic Shutter
1/180000 to 30 Seconds in Program Mode
1/180000 to 30 Seconds in Aperture Priority Mode
1/180000 to 15 Minutes in Shutter Priority Mode
1/180000 to 15 Minutes in Manual Mode
Fixed 1 Second in Bulb Mode
Electronic Front Curtain Shutter
1/8000 to 30 Seconds in Program Mode
1/8000 to 30 Seconds in Aperture Priority Mode
1/8000 to 15 Minutes in Shutter Priority Mode
1/8000 to 15 Minutes in Manual Mode
Up to 60 Minutes in Bulb Mode
Bulb/Time Mode Bulb Mode
ISO Sensitivity Photo
125 to 12,800 in Manual, Auto Mode (Extended: 80 to 51,200)
Video
125 to 12,800 in Manual Mode (Extended: 125 to 256,000)
Metering Method Average, Center-Weighted Average, Multi-Zone, Spot
Exposure Modes Aperture Priority, Manual, Program, Shutter Priority
Exposure Compensation -5 to +5 EV (1/3 EV Steps)
White Balance 2500 to 10,000K
Presets: Auto, Custom 1, Custom 2, Daylight, Fluorescent, Shade, Tungsten, Underwater
Continuous Shooting Electronic Shutter
Up to 20 fps at 40.2 MP for up to 168 Frames (JPEG) / 37 Frames (Raw)
Electronic Shutter
Up to 13 fps at 40.2 MP for up to 1000 Frames (JPEG) / 23 Frames (Raw)
Electronic Shutter
Up to 10 fps at 40.2 MP for up to 1000 Frames (JPEG) / 25 Frames (Raw)
Mechanical Shutter
Up to 15 fps at 40.2 MP for up to 119 Frames (JPEG) / 19 Frames (Raw)
Mechanical Shutter
Up to 10 fps at 40.2 MP for up to 1000 Frames (JPEG) / 19 Frames (Raw)
Mechanical Shutter
Up to 7 fps at 40.2 MP for up to 1000 Frames (JPEG) / 20 Frames (Raw)
Interval Recording Yes
Self-Timer 2/10-Second Delay
Still Image Capture
Image Sizes 3:2
7728 x 5152
5472 x 3648
3888 x 2592
1:1
5152 x 5152
3648 x 3648
2592 x 2592
16:9
7728 x 4344
5472 x 3080
3888 x 2184
Aspect Ratio 1:1, 3:2, 16:9
Image File Format HEIF, JPEG, Raw, TIFF
Bit Depth 14-Bit
Video Capture
Internal Recording Modes H.264/H.265/MP4/MPEG-4 4:2:2 10-Bit
6240 x 3140 at 23.98/24.00/25/29.97 fps [50 to 360 Mb/s]
DCI 4K (4096 x 2160) at 23.98/24.00/25/29.97/50/59.94 fps [50 to 360 Mb/s]
UHD 4K (3840 x 2160) at 23.98/24.00/25/29.97/50/59.94 fps [50 to 720 Mb/s]
DCI 2K (2048 x 1080) at 23.98/24.00/25/29.97/50/59.94 fps [50 to 360 Mb/s]
1920 x 1080 at 23.98/24.00/25/29.97/50/59.94 fps [50 to 360 Mb/s]
2048 x 1080 at 100/119.88/200/239.76 fps [200 to 360 Mb/s]
1920 x 1080 at 100/119.88/200/239.76 fps [200 to 360 Mb/s]
Gamma Curve FUJIFILM F-Log, FUJIFILM F-Log 2
Broadcast Output NTSC/PAL
Built-In Microphone Type Stereo
Audio Recording MOV: 2-Channel 24-Bit 48 kHz
MPEG4: 2-Channel 24-Bit 48 kHz LPCM Audio
MP4: 2-Channel AAC Audio
Interface
Media/Memory Card Slot Dual Slot: SD/SDHC/SDXC (UHS-II) [2 TB Maximum / V90 or Faster Recommended]
Video I/O 1 x Micro-HDMI Output
Audio I/O 1 x 1/8" / 3.5 mm TRS Stereo Microphone (Plug-in Power) Input on Camera Body
Power I/O 1 x USB-C Input/Output
Other I/O 1 x 2.5 mm Sub-Mini (Camera Interface) Control
Wireless Wi-Fi 5 (802.11ac), Wi-Fi 4 (802.11n), Wi-Fi (802.11b/g), Bluetooth Control
Global Positioning (GPS, GLONASS, etc.) None
Monitor
Size 3"
Resolution 1,084,000 Dot
Display Type Tilting Touchscreen LCD
Viewfinder
Type Built-In Electronic (OLED)
Size 0.5"
Resolution 3,690,000 Dot
Eye Point 24 mm
Coverage 100%
Magnification Approx. 0.8x
Diopter Adjustment -5 to +3
Focus
Focus Type Auto and Manual Focus
Focus Mode Continuous-Servo AF, Manual Focus, Single-Servo AF
Autofocus Points Photo, Video
Contrast Detection, Phase Detection: 425
Flash
Flash Modes Auto, Commander, First-Curtain Sync, Manual, Off, Second-Curtain Sync, Slow Sync
Maximum Sync Speed 1/250 Second
Dedicated Flash System TTL
External Flash Connection Hot Shoe, PC Terminal
Environmental
Operating Temperature 14 to 104°F / -10 to 40°C
Operating Humidity 10 to 80%
General
Battery Type 1 x NP-W235 Rechargeable Lithium-Ion (Approx. 580 Shots)
Tripod Mounting Thread 1 x 1/4"-20 Female (Bottom)
Dimensions (W x H x D) 5.1 x 3.6 x 2.5" / 129.5 x 91 x 63.8 mm
Weight 19.6 oz / 557 g (With Battery, Recording Media)
16.8 oz / 476 g (Body Only)
FUJIFILM XF 16-80mm F/4 R OIS WR Lens Specs
Focal Length 16 to 80mm (35mm Equivalent Focal Length: 24 to 120mm)
Maximum Aperture f/4
Minimum Aperture f/22
Lens Mount FUJIFILM X
Lens Format Coverage APS-C
Angle of View 83.2° to 20.1°
Minimum Focus Distance 1.15' / 35 cm
Maximum Magnification 0.25x
Optical Design 16 Elements in 12 Groups
Diaphragm Blades 9, Rounded
Focus Type Autofocus
Image Stabilization Yes
Filter Size 72 mm (Front)
Dimensions (ø x L) 3.08 x 3.5" / 78.3 x 88.9 mm
Length at Maximum Extension 5.16" / 131 mm
Weight 15.52 oz / 440 g
Packaging Info
Package Weight 1.9 lb
Box Dimensions (LxWxH) 8.3 x 5.6 x 5.5"
