Type | Single-lens reflex digital camera |
Lens mount | Nikon F mount (with AF coupling and AF contacts) |
Image sensor format | FX |
Image sensor type | CMOS |
Sensor size | 35.9 mm x 23.9 mm |
Total pixels | 21.33 million |
Dust-reduction system | Image sensor cleaning, Image Dust Off reference data (Capture NX-D software required) |
Effective pixels | 20.8 million |
Image size (pixels) | [FX (36 x 24)] selected for image area: (L) 5568 x 3712 ( 20.7 million) (M) 4176 x 2784 ( 11.6 million) (S) 2784 x 1856 ( 5.2 million) [1.2 x (30 x 20)] selected for image area: (L) 4640 x 3088 ( 14.3 million) (M) 3472 x 2312 ( 8.0 million) (S) 2320 x 1544 ( 3.6 million) [DX (24 x 16)] selected for image area: (L) 3648 x 2432 ( 8.9 million) (M) 2736 x 1824 ( 5.0 million) (S) 1824 x 1216 ( 2.2 million) [5:4 (30 x 24)] selected for image area: (L) 4640 x 3712 ( 17.2 million) (M) 3472 x 2784 ( 9.7 million) (S) 2320 x 1856 ( 4.3 million) [1:1 (24 x 24)] selected for image area: (L) 3712 x 3712 ( 13.8 million) (M) 2784 x 2784 ( 7.8 million) (S) 1856 x 1856 ( 3.4 million) [16:9 (36 x 20)] selected for image area: (L) 5568 x 3128 ( 17.4 million) (M) 4176 x 2344 ( 9.8 million) (S) 2784 x 1560 ( 4.3 million) Photographs taken while filming movies at a frame size of 3840 x 2160: 3840 x 2160 Photographs taken while filming movies at a frame size of 1920 x 1080: 1920 x 1080 Photographs taken while filming movies at a frame size of 1280 x 720: 1280 x 720 |
File format | NEF (RAW): 12 or 14 bit (lossless compressed, compressed, or uncompressed); large, medium, and small available (medium and small images are recorded at a bit depth of 12 bits using lossless compression) JPEG: JPEG-Baseline compliant with fine (approx. 1:4), normal (approx. 1:8), or basic (approx. 1:16) compression; size-priority and optimal-quality compression available NEF (RAW)+JPEG: Single photograph recorded in both NEF (RAW) and JPEG formats |
Picture Control system | Auto, Standard, Neutral, Vivid, Monochrome, Portrait, Landscape, Flat Creative Picture Controls (Dream, Morning, Pop, Sunday, Sombre, Dramatic, Silence, Bleached, Melancholic, Pure, Denim, Toy, Sepia, Blue, Red, Pink, Charcoal, Graphite, Binary, Carbon); selected Picture Control can be modified; storage for custom Picture Controls |
Media | CFexpress (Type B) and XQD memory cards |
Card slot | 2 CFexpress (Type B) cards or 2 XQD cards The card in Slot 2 can be used for overflow or backup storage, for separate storage of NEF (RAW) and JPEG copies of photos taken at image quality settings of NEF (RAW) + JPEG, or to store separate copies of JPEG photos at different sizes and compression ratios; pictures can be copied between cards |
File system | DCF 2.0, Exif 2.31 |
Viewfinder | Eye-level pentaprism single-lens reflex viewfinder |
Frame coverage | FX: Approx. 100% horizontal and 100% vertical 1.2x: Approx. 97% horizontal and 97% vertical DX: Approx. 97% horizontal and 97% vertical 5:4: Approx. 97% horizontal and 100% vertical 1:1: Approx. 95% horizontal and 100% vertical 16:9: Approx. 100% horizontal and 96% vertical |
Magnification | Approx. 0.72x (50 mm f/1.4 lens at infinity, -1.0 m(*1)) |
Eyepoint | 17 mm (-1.0m(*1); from centre surface of viewfinder eyepiece lens) |
Diopter adjustment | -3 to +1 m(*1) |
Focusing screen | Type B BriteView Clear Matte Mark X screen (with AF-area brackets; framing grid can be displayed) |
Reflex mirror | Quick return |
Depth-of-field preview | Yes Pressing Pv button stops lens aperture down to value selected by user (A and M modes) or by camera (P and S modes) |
Lens aperture | Instant return, electronically controlled |
Compatible lenses | Types G, E, and D (some restrictions apply to PC lenses) Other AF NIKKOR lenses (excluding IX NIKKOR lenses and lenses for the F3AF) AI-P NIKKOR lenses DX lenses (using [DX (24 x 16)] image area) Non-CPU AI lenses (modes A and M only) During viewfinder photography, the electronic rangefinder can be used with lenses that have a maximum aperture of f/5.6 or faster. With lenses that have a maximum aperture of f/8 or faster, the electronic rangefinder supports 15 focus points. |
Type | Electronically-controlled vertical-travel focal-plane mechanical shutter; electronic front-curtain shutter; electronic shutter |
Speed | 1/8000 to 30 s (choose from step sizes of 1/3, 1/2, and 1 EV, extendable to 900 s in mode M), Bulb; Time; X250 |
Flash sync speed | X= 1/250 s; synchronizes with shutter at 1/250 s or slower Auto FP high-speed sync supported |
Modes | S (single frame), CL (continuous low speed), CH (continuous high speed), Q (quiet shutter-release), Self-timer, MUP (mirror up) |
Approximate frame advance rate | Up to 14 fps CL: 1 to 10 fps CH: 10 to 14 fps Q: 1 to 5 fps |
Self-timer | 2 s, 5 s, 10 s, 20 s; 1 to 9 exposures at intervals of 0.5, 1, 2, or 3 s |
Metering system | Viewfinder photography: TTL exposure metering using RGB sensor with approximately 180K (180,000) pixels Live view: TTL exposure metering performed by image sensor |
Metering mode | Matrix: 3D colour matrix metering III (type G, E, and D lenses); colour matrix metering III (other CPU lenses); colour matrix metering available with non-CPU lenses if user provides lens data Centre-weighted: Weight of 75% given to 12 mm circle in centre of frame; diameter of circle can be changed to 8, 15, or 20 mm, or weighting can be based on average of entire frame (non-CPU and AF-S Fisheye NIKKOR 8–15mm f/3.5– 4.5E ED lenses use 12-mm circle) Spot: Meters circle approximately 4 mm in diameter (about 1.5% of frame) centred on selected focus point (on centre focus point when non-CPU or AF-S Fisheye NIKKOR 8–15mm f/3.5–4.5E ED lens is used) Highlight-weighted: Available with type G, E, and D lenses |
Range* | Matrix or centre-weighted metering: -3 to +20 EV Spot metering: 2 to 20 EV Highlight-weighted metering: 0 to 20 EV * Figures are for ISO 100 and f/1.4 lens at 20 °C/68 °F |
Exposure meter coupling | CPU, AI |
Mode | P (programmed auto with flexible program); S (shutter-priority auto); A (aperture-priority auto); M (manual) |
Exposure compensation | –5 to +5 EV; -3 to +3 EV when filming movies (choose from step sizes of 1/3, 1/2, and 1 EV) |
Exposure lock | Luminosity locked at detected value |
ISO sensitivity (Recommended Exposure Index) | ISO 100 to 102400 (choose from step sizes of 1/3, 1/2, and 1 EV); can also be set to approx. 0.3, 0.5, 0.7, or 1 EV (ISO 50 equivalent) below ISO 100 or to approx. 0.3, 0.5, 0.7, 1, 2, 3, 4, or 5 EV (ISO 3280000 equivalent) above ISO 102400; auto ISO sensitivity control available |
Active D-Lighting | Can be selected from Auto, Extra high +2, Extra high +1, High, Normal, Low, and Off |
Type | Viewfinder photography: TTL phase-detection; 105 focus points, all of which are cross-type sensors and 15 of which support f/8; detection performed by Multi-CAM 37K autofocus sensor module; autofocus fine-tuning supported Live view: Contrast-detect AF available at all points in frame; focus point selected by camera when face detection or subject-tracking is used |
Detection Range | -4.5 to +20 EV (ISO 100, 20 °C/68 °F) |
Lens servo | Single-servo AF (AF-S), continuous-servo AF (AF-C; predictive focus tracking activated automatically according to subject status), full-time AF (AF-F; available only during live view and movie recording) Manual focus (M): Electronic rangefinder can be used |
Focus points | 105 focus points (number available for selection in viewfinder photography can be chosen from 105, 27, and 15) |
AF-area mode | Viewfinder photography: Single-point AF; 9-, 25-, 49-, or 105- point dynamic-area AF; 3D-tracking; group-area AF; group-area AF (C1); group-area AF (C2); auto-area AF Live view: Face-detection AF, wide-area AF, normal-area AF, subject-tracking AF |
Focus lock | Focus can be locked by pressing shutter-release button halfway (single-servo AF/AF-S) or by pressing the centre of the sub-selector |
Control | TTL flash control using RGB sensor with approximately 180K (180,000) pixels: i-TTL flash control; i-TTL balanced fill-flash for digital SLR is used with matrix, centre-weighted, and highlight-weighted metering, standard i-TTL fill-flash for digital SLR with spot metering |
Mode | Front-curtain sync, red-eye reduction, slow sync, red-eye reduction with slow sync, rear-curtain sync, off |
Flash compensation | –3 to +1 EV (choose from step sizes of 1/3, 1/2 and 1 EV) |
Flash-ready indicator | Lights when optional flash unit is fully charged; flashes after flash is fired at full output |
Accessory shoe | ISO 518 hot-shoe with sync and data contacts and safety lock |
Nikon Creative Lighting System (CLS) | i-TTL flash control, radio-controlled Advanced Wireless Lighting, optical Advanced Wireless Lighting, modelling illumination, FV lock, Colour Information Communication, auto FP high-speed sync, AF-assist for multi-area AF (viewfinder photography), unified flash control |
Sync terminal | ISO 519 sync terminal with locking thread |
White balance | Auto (3 types), natural light auto, direct sunlight, cloudy, shade, incandescent, fluorescent (7 types), flash, choose colour temperature (2500 K to 10,000 K), present manual (up to 6 values can be stored, spot white balance measurement available during live view), all with fine-tuning |
Bracketing types | Exposure and/or flash, white balance, and ADL |
Modes | Photo live view, Movie live view |
Metering system | TTL metering using camera image sensor |
Metering mode | Matrix, centre-weighted, or highlight-weighted |
Frame size (pixels) and frame rate | 3840 x 2160 (4K UHD); 30p (progressive), 25p, 24p 1920 x 1080; 60p, 50p, 30p, 25p, 24p 1280 x 720: 60p, 50p 1920 x 1080 crop: 60p, 50p, 30p, 25p, 24p * Actual frame rates for 60p, 50p, 30p, 25p, and 24p are 59.94, 50, 29.97, 25, and 23.976 fps respectively * Quality selection available at all sizes except 3840 x 2160, when quality is fixed at high |
File format | MOV, MP4 |
Video compression | H.264/MPEG-4 Advanced Video Coding |
Audio recording format | Linear PCM (for movies recorded in MOV format), AAC (for movies recorded in MP4 format) |
Audio recording device | Built-in stereo or external microphone with attenuator option; sensitivity adjustable |
ISO sensitivity (Recommended Exposure Index) | Mode M: Manual selection (ISO 100 to 102400; choose from step sizes of 1/3, 1/2, and 1 EV) with additional options available equivalent to approximately 0.3, 0.5, 0.7, 1, 2, 3, 4, or 5 EV (ISO 3280000 equivalent) above ISO 102400; auto ISO sensitivity control (ISO 100 to Hi 5) available with selectable upper limit Modes P, S, and A: Auto ISO sensitivity control (ISO 100 to Hi 5) with selectable upper limit |
Active D-Lighting | Can be selected from Extra high, High, Normal, Low, and Off |
Other options | Time-lapse movie recording, electronic vibration reduction, time codes |
Monitor size | 8 -cm ( 3.2 –in.) |
Monitor resolution | Approx. 2359 k-dot (XGA) TFT touch-sensitive LCD with 170 ° viewing angle, approximately 100% frame coverage, 11-level manual brightness adjustment, and colour balance control |
Playback | Full-frame and thumbnail (4, 9, or 72 images) playback with playback zoom, playback zoom cropping, movie playback, photo and/or movie slide shows, histogram display, highlights, photo information, location data display, picture rating, auto image rotation, index marking, voice memo input and playback, and IPTC information embedding and display |
USB connector | Type C USB connector (SuperSpeed USB); connection to built-in USB port is recommended |
HDMI output connector | Type C HDMI connector |
Audio input | Stereo mini-pin jack (3.5 mm diameter; plug-in power supported) |
Audio output | Stereo mini-pin jack (3.5 mm diameter) |
Ten-pin remote terminal | Built-in (can be used with MC-30A/MC-36A remote cords and other optional accessories) |
Ethernet connector | RJ-45 connector Standards: IEEE 802.3ab (1000BASE-T)/IEEE 802.3u (100BASE-TX)/IEEE 802.3 (10BASE-T) Data rates : 10/100/1000 Mbps with auto detect Port: 1000BASE-T/100BASE-TX/10BASE-T (AUTOMDIX) * Maximum logical data rates according to IEEE standard; actual rates may differ. |
Peripheral connector | For WT-6 |
Wi-Fi Africa, Asia (except China, Japan, Korea), Middle East, Oceania | • IEEE 802.11b/g/n 2412 to 2462 MHz (channel 11) 2.4 GHz band: 2.9 dBm Open system, WPA2-PSK |
Bluetooth | Bluetooth Specification Version 4.2 Bluetooth: 2402 to 2480 MHz Bluetooth Low Energy: 2402 to 2480 MHz Bluetooth: 1.3 dBm Bluetooth Low Energy: -0.2 dB |
Range (line of sight) | Approximately 10 m (32 ft) * Without interference. Range may vary with signal strength and presence or absence of obstacles. |
Supported GNS systems | GPS (USA), GLONASS (Russia), QZSS (Japan) |
Data acquired | Latitude, longitude, altitude, UTC (Universal Coordinated Time) |
Clock synchronization | Camera clock can be set to time acquired via GNSS |
Track logs | NMEA-compliant |
Log interval | 15 s, 30 s, 1 min., 2 min., 5 min. |
Maximum log recording time | 6, 12, or 24 hours |
Log deletion | Supported |
Battery | One EN-EL18c rechargeable Li-ion battery* * EN-EL18b/EN-EL18a/EN-EL18 batteries can also be used. Note, however, that fewer pictures can be taken on a single charge with an EN-EL18 than with an EN-EL18c/EN-EL18b/EN-EL18a. |
AC adapter | EH-6c AC adapter; requires EP-6 power connector (available separately) |
Tripod socket | 1/4–in. (ISO 1222) |
Dimensions (W x H x D) | Approx. 160 x 163 x 92 mm |
Weight | Approx. 1450g with battery and two CFexpress memory cards but without body cap and accessory shoe cover; approx. 1270g (camera body only) |
Operating environment | Temperature: 0°C to 40°C
Humidity: 85% or less (no condensation) |
