Guide Number (ISO 100•m) | GN 58 (Firing angle: 100mm) GN 14 (Firing angle: 7mm)[*] • When using the built-in wide panel |
Firing Angle | Covers the angle of view of a 12mm to 100mm Micro Four Thirds lens (35mm equivalent: 24mm to 200mm) Covers the angle of view of a 7mm to 10mm Micro Four Thirds lens (35mm equivalent: 14mm to 20mm)[*] • When using the built-in wide panel |
Built-in Functions | Wide panel, catch light plate |
Flash Modes | TTL-Auto, Auto, Manual, FP TTL-Auto, FP Manual, and Multi |
Flash Emission Period | Approx. 1/20000 to 1/500 sec. (except when using Super FP flash) |
Remote Control (RC) | Flash mode: RC, SL Auto, SL Manual 4 channels Can control 4 groups of flashes independently from each other (3 slave flash groups + flash on camera body) |
Bounce Angle | Up: 0 to 90 degrees, down: 0 to 7 degrees, right: 0 to 180 degrees, left: 0 to 180 degrees |
LED | Power: 1.5 W Color: White Firing Angle: approx. 70 degrees Illuminance: 100 Lux @ 1 m Control mode: Auto, Manual, and Off with adjustment possible by 1 EV step from Full to 1/32 |
Power Supply | 4 AA (R6) alkaline batteries 4 AA (R6) NiMH batteries (Recommended) |
Charging Time[1] | Approx. 4.5 sec. (when using AA alkaline batteries) Approx. 2.5 sec. (when using AA NiMH batteries) |
Flash Emission Count[1] | Approx. 160 times (when using AA alkaline batteries) Approx. 200 times (when using AA NiMH batteries) |
LED Emission Time[1] | Approx. 2.4 hours (when using AA alkaline batteries) Approx. 2.6 hours (when using AA NiMH batteries) |
Operating Environment[2] | -10°C to 40°C |
Size | W 81.2 mm x H 121.4 mm x D 125.2 mm (excluding protrusions) |
Weight | 382 g (excluding batteries) |
Box Contents | Flash stand FLST-1, flash case, bounce adapter, IR filter, instruction manual, Warranty Card |
