| Lens Mount |
Micro Four Thirds
|
| Sensor Resolution |
Actual: 22.9 Megapixel
|
| Effective: 20.4 Megapixel |
| Image Sensor |
17.4 x 13 mm (Four Thirds) BSI MOS
|
| Sensor Crop (35mm Equivalent) |
Crop Factor: 2x
|
| Image Stabilization |
Sensor-Shift, 5-Axis
|
| Capture Type |
Stills & Video
|
| Shutter Type |
Mechanical Focal Plane Shutter and Electronic Rolling Shutter
|
| Shutter Speed |
Mechanical Shutter
|
| 1/8000 to 60 Seconds |
| Electronic Shutter |
| 1/32000 to 60 Seconds |
| Electronic Front Curtain Shutter |
| 1/320 to 60 Seconds |
| Bulb/Time Mode |
Bulb Mode, Time Mode
|
| ISO Sensitivity Range |
Photo/Video
|
| 200 to 25,600 in Manual, Auto Mode (Extended: 80 to 102,400) |
| Metering Method |
Center-Weighted Average, Highlight, Multi-Zone, Spot
|
| Precise Scan Rate Control |
Yes
|
| Exposure Modes |
Aperture Priority, Manual, Program, Shutter Priority
|
| Exposure Compensation |
-5 to +5 EV (1/3, 1/2, 1 EV Steps)
|
| Metering Range |
-2 to 20 EV
|
| White Balance |
2000 to 14,000K
|
| Presets: AWB, Custom, Flash, Fluorescent, Overcast, Shade, Sunlight, Tungsten, Underwater |
| Continuous Shooting |
Up to 120 fps
|
| Interval Recording |
Yes
|
| Image Sizes |
4:03
|
| 50 MP (8160 x 6120) *Via In-Camera Pixel-Shift |
| 25 MP (5760 x 4320) *Via In-Camera Pixel-Shift |
| 20 MP (5184 x 3888) |
| Aspect Ratio |
1:1, 3:2, 4:3, 16:9
|
| Image File Format |
JPEG, Raw
|
| Bit Depth |
12-Bit
|
| Internal Recording Modes |
H.264/MPEG-4 AVC
|
| 4096 x 2160 at 23.98/25/29.97/50/59.94 fps [202 Mb/s] |
| 3840 x 2160 at 23.98/25/29.97/50/59.94 fps [202 Mb/s] |
| 1920 x 1080 at 23.98/25/29.97/50/59.94/100/120/200/240 fps [202 Mb/s] |
| H.265 |
| 4096 x 2160 at 23.98/25/29.97/50/59.94 fps [152 Mb/s] |
| 3840 x 2160 at 23.98/25/29.97/50/59.94 fps [152 Mb/s] |
| 1920 x 1080 at 23.98/25/29.97/50/59.94/100/120/200 fps [162 Mb/s] |
| External Recording Modes |
4:2:2 8-Bit via HDMI
|
| 4096 x 2160 |
| 3840 x 2160 |
| 1920 x 1080 |
| Fast-/Slow-Motion Support |
Slow-Motion Only
|
| Gamma Curve |
FLAT, HDR-HLG, OM-Log
|
| Recording Limit |
No
|
| IP Streaming |
No
|
| Built-In Microphone Type |
Stereo
|
| Audio Recording |
16-Bit 48 kHz LPCM Audio
|
| Media/Memory Card Slot |
Dual Slot: SD/SDHC/SDXC (UHS-II)
|
| Video I/O |
1x Micro-HDMI (Unspecified Signal) Output
|
| Audio I/O |
1x 1/8" / 3.5 mm TRS Stereo Microphone Input
|
| 1x 1/8" / 3.5 mm TRS Stereo Headphone Output |
| Power I/O |
1x USB-C Input/Output
|
| Other I/O |
1x USB-C Data Input/Output (Shared with Power Input)
|
| 1x PC Sync Socket |
| Wireless |
2.4 / 5 GHz Wi-Fi 5 (802.11ac), Bluetooth 4.2
|
| Mobile App Compatible |
Yes: Android & iOS
|
| App Name: OM Image Share |
| Functionality: Access Stored Files, Remote Control, View Live Feed |
| Global Positioning (GPS, GLONASS, etc.) |
GPS
|
| *Via Connected Smartphone |
| Display Size |
3"
|
| Resolution |
1,620,000 Dot
|
| Display Type |
Articulating Touchscreen LCD
|
| Type |
Built-In Electronic (OLED)
|
| Resolution |
5,760,000 Dot
|
| Eye Point |
21 mm
|
| Coverage |
100%
|
| Magnification |
Approx. 1.48x
|
| Diopter Adjustment |
-4 to +2
|
|
|
|
| Focus Type |
Auto and Manual Focus
|
| Focus Mode |
Continuous-Servo AF, Manual Focus, Single-Servo AF
|
| Autofocus Points |
Photo, Video
|
| Phase Detection: 1053 |
| Built-In Flash/Light |
No
|
| Flash Modes |
Fill In, Manual, Off, Red-Eye Reduction, Slow Sync
|
| Maximum Sync Speed |
1/250 Second
|
| Flash Compensation |
-3 to +3 EV (1/3, 1/2, 1 EV Steps)
|
| Dedicated Flash System |
TTL
|
| External Flash Connection |
Shoe Mount, PC Terminal
|
| Operating Temperature |
14 to 104°F / -10 to 40°C
|
| Storage Temperature |
-4 to 140°F / -20 to 60°C
|
| Operating Humidity |
30 to 90%
|
| Storage Humidity |
10 to 90%
|
| Battery Type |
1x BLX-1 Rechargeable Lithium-Ion
|
| Shoe Mount |
1x Hot Shoe
|
| Tripod Mounting Thread |
1x 1/4"-20 Female (Bottom)
|
| Material of Construction |
Magnesium Alloy
|
| Dimensions (W x H x D) |
134.8 x 91.6 x 72.7 mm
|
| Weight |
511 g (Body Only)
|
