Lens Mount |
Micro Four Thirds
|
Sensor Resolution |
Actual: 26.52 Megapixel
|
Effective: 25.2 Megapixel (5776 x 4336) |
Image Sensor |
17.3 x 13 mm (Four Thirds) BSI CMOS
|
Sensor Crop (35mm Equivalent) |
Crop Factor: 2x
|
*Additional Crop Occurs in Select Video Modes |
Image Stabilization |
Sensor-Shift, 5-Axis
|
Built-In ND Filter |
No
|
Capture Type |
Stills & Video
|
Shutter Type |
Mechanical Focal Plane Shutter and Electronic Rolling Shutter
|
Shutter Speed |
Mechanical Shutter
|
1/8000 to 60 Seconds |
Up to 30 Minute in Bulb Mode |
Electronic Front Curtain Shutter |
1/2000 to 60 Seconds |
Up to 30 Minutes in Bulb Mode |
Electronic Shutter |
1/32000 to 60 Seconds |
Up to 60 Seconds in Bulb Mode |
Bulb/Time Mode |
Bulb Mode
|
ISO Sensitivity Range |
|
100 to 25,600 (Extended: 50 to 25,600) |
Video |
100 to 12,800 (Extended: 50 to 12,800) |
Metering Method |
Center-Weighted Average, Highlight Weighted, Multiple, Spot
|
Exposure Modes |
Aperture Priority, Auto, Manual, Program, Shutter Priority
|
Exposure Compensation |
-5 to +5 EV (1/3 EV Steps)
|
Metering Range |
0 to 18 EV
|
White Balance |
2500 to 10,000K
|
Presets: AWB, Auto, Cloudy, Color Temperature, Daylight, Flash, Incandescent, Shade, White Set 1, White Set 2, White Set 3, White Set 4 |
Continuous Shooting |
Mechanical Shutter
|
Up to 14 fps at 25.2 MP for up to 215 Frames (Raw) / 260 Frames (JPEG) |
Electronic Shutter |
Up to 75 fps at 25.2 MP for up to 215 Frames (Raw) / 260 Frames (JPEG) |
Self-Timer |
2/3/10-Second Delay
|
Image Sizes |
4:03
|
100 MP (11,552 x 8672) *Via In-Camera Pixel-Shift |
50.5 MP (8192 x 6144) *Via In-Camera Pixel-Shift |
25 MP (5776 x 4336) |
12.5 MP (4096 x 3072) |
6.5 MP (2944 x 2208) |
5 MP (1920 x 1440) |
3:02 |
89 MP (11,552 x 7696) *Via In-Camera Pixel-Shift |
44.5 MP (8192 x 5464) *Via In-Camera Pixel-Shift |
22 MP (5776 x 3848) |
11 MP (4096 x 2728) |
5.5 MP (2944 x 1960) |
5 MP (1920 x 1280) |
16:09 |
75 MP (11,552 x 6496) *Via In-Camera Pixel-Shift |
37.5 MP (8192 x 4608) *Via In-Camera Pixel-Shift |
18.5 MP (5776 x 3242) |
9.5 MP (4096 x 2304) |
5 MP (2944 x 1656) |
5 MP (1920 x 1080) |
1:01 |
75 MP (8672 x 8672) *Via In-Camera Pixel-Shift |
37.5 MP (6144 x 6144) *Via In-Camera Pixel-Shift |
19 MP (4336 x 4336) |
9.5 MP (3072 x 3072) |
5 MP (2208 x 2208) |
5 MP (1440 x 1440) |
Aspect Ratio |
1:1, 3:2, 4:3, 16:9
|
Image File Format |
JPEG, Raw
|
Internal Recording Modes |
ProRes RAW/ProRes RAW HQ
|
5728 x 3024 at 23.98/24.00/25/29.97/50 fps [1 to 4.2 Gb/s] |
4096 x 2160 at 23.98/24.00/25/29.97/50/59.94 fps [1.1 to 4.2 Gb/s] |
H.264/MOV/MPEG-4 AVC/ProRes 422/ProRes 422 HQ 4:2:2 10-Bit |
5728 x 3024 at 23.98/24.00/25/29.97 fps [1000 to 1900 Mb/s] |
H.264 ALL-Intra/MOV 4:2:2 10-Bit |
4096 x 2160 from 1 to 59.94 fps [400 to 800 Mb/s] |
3840 x 2160 from 1 to 59.94 fps [400 to 800 Mb/s] |
1920 x 1080p from 1 to 240 fps [200 to 800 Mb/s] |
1920 x 1080i at 50/59.94 fps [100 Mb/s] |
H.264 Long GOP/MOV/MPEG-4 AVC 4:2:2 10-Bit |
4096 x 2160 from 1 to 59.94 fps [150 to 200 Mb/s] |
3840 x 2160 from 1 to 59.94 fps [150 to 200 Mb/s] |
1920 x 1080p from 1 to 240 fps [100 to 200 Mb/s] |
1920 x 1080i at 50/59.94 fps [50 Mb/s] |
H.265 Long GOP/MOV 4:2:0 10-Bit |
5760 x 4320 at 23.98/24.00/25/29.97 fps [200 Mb/s] |
5728 x 3024 from 1 to 59.94 fps [200 to 300 Mb/s] |
4352 x 3264 at 47.95/48.00/50/59.94 fps [300 Mb/s] |
4096 x 2160 [150 to 300 Mb/s] |
3840 x 2160 [72 to 300 Mb/s] |
1920 x 1080p from 1 to 300 fps [20 to 200 Mb/s] |
External Recording Modes |
4:2:2 10-Bit via HDMI
|
DCI 4K (4096 x 2160) at 23.98/24.00/25/29.97/50/59.94 fps |
UHD 4K (3840 x 2160) at 23.98/24.00/25/29.97/50/59.94 fps |
1920 x 1080p at 23.98/24.00/25/29.97/50/59.94 fps |
1920 x 1080i at 50/59.94 fps |
Raw 12-Bit via HDMI |
5760 x 4320 |
5744 x 3024 |
DCI 4K (4096 x 2160) |
Fast-/Slow-Motion Support |
Yes
|
Gamma Curve |
Panasonic V-Gamut, Panasonic V-Log
|
Recording Limit |
No
|
IP Streaming |
RTMP, RTMPS
|
1280 x 720 to 1920 x 1080 at 29.97p, 59.94p (4.0 to 16.00 Mb/s) |
RTMP, RTMPS, UVC/UAC |
1280 x 720 to 1920 x 1080 at 25p, 29.97p, 50p, 59.94p (4.0 to 16.00 Mb/s) |
3840 x 2160 at 29.97p (4.0 to 16.00 Mb/s) |
RTP, RTSP |
1280 x 720 to 3840 x 2160 at 25p, 29.97p, 50p, 59.94p (4.0 to 50.00 Mb/s) |
Built-In Microphone |
Stereo
|
Audio Recording |
MOV: 2/4-Channel 24-Bit 96 kHz LPCM Audio
|
MOV: 2/4-Channel 24-Bit 48 kHz LPCM Audio |
MP4: 2-Channel 16-Bit 48 kHz AAC Audio |
Media/Memory Card Slot |
Slot 1: CFexpress Type B
|
Slot 2: SD/SDHC (UHS-II) [U3/V30 or Faster Recommended] |
Video I/O |
1x HDMI (Unspecified Signal) Output
|
Audio I/O |
1x 1/8" / 3.5 mm TRRS Headphone/Mic Microphone Input
|
1x 1/8" / 3.5 mm TRRS Headphone/Mic Headphone Output |
Power I/O |
1x USB-C Input/Output
|
Other I/O |
1x USB-C Data/Monitor/Tether/Video
|
Wireless |
5 GHz Wi-Fi 5 (802.11ac), Bluetooth 5.0 Video Output, Audio Output, Control
|
Mobile App Compatible |
Yes: Android & iOS
|
App Name: Panasonic LUMIX Sync |
Functionality: Access Stored Files, Adjust Settings, Firmware Update, Remote Control, View Live Feed |
Global Positioning (GPS, GLONASS, etc.) |
GPS
|
*Via Connected Smartphone |
Display Size |
3"
|
Resolution |
1,840,000 Dot
|
Display Type |
Free-Angle Tilting Touchscreen LCD
|
Type |
Built-In Electronic (OLED)
|
Resolution |
3,680,000 Dot
|
Eye Point |
21 mm
|
Coverage |
100%
|
Magnification |
Approx. 0.76x
|
Diopter Adjustment |
-4 to +3
|
Focus Type |
Auto and Manual Focus
|
Focus Mode |
Automatic, Continuous-Servo AF, Focus Lock AF Area Mode, Manual Focus, Single-Servo AF, Touch AF & Shutter
|
Autofocus Points |
Photo, Video
|
Contrast Detection: 315 |
Autofocus Sensitivity |
-4 to +18 EV
|
Built-In Flash/Light |
No
|
Flash Modes |
Auto, Auto/Red-Eye Reduction, Forced On, Forced On/Red-Eye Reduction, Off, Slow Sync, Slow Sync/Red-Eye Reduction
|
Maximum Sync Speed |
1/250 Second
|
Flash Compensation |
-3 to +3 EV (1/3 EV Steps)
|
Dedicated Flash System |
TTL
|
External Flash Connection |
Shoe Mount
|
Operating Temperature |
14 to 104°F / -10 to 40°C
|
Operating Humidity |
10 to 80%
|
Battery Type |
1x DMW-BLK22 Rechargeable Lithium-Ion, 7.2 VDC, 2200 mAh (Approx. 350 Shots)
|
Shoe Mount |
1x Hot Shoe
|
Tripod Mounting Thread |
1x 1/4"-20 Female (Bottom)
|
Material of Construction |
Magnesium Alloy
|
Dimensions (W x H x D) |
13.84 x 10.03 x 9.96 cm
|
Weight |
805 g (With Battery, Recording Media)
|
721 g (Body Only) |
