| Lens Construction |
7 elements in 5 groups (2 aspherical lens elements) |
| Focal Length, Aperture |
26.1mm (Approx. 40mm in 35mm equivalent focal length), F2.8～F16 |
| Image Sensor |
Type: Primary color filter CMOS. Size: 23.5mm x 15.6mm |
| Effective Pixels |
Approx. 24.24 megapixels |
| Sensitivity (Standard output) |
ISO100～102400: Auto (ISO Auto Lower/Upper Limit and Minimum Shutter Speed can be set), Manual |
| Image Stabilization |
Sensor-shift shake reduction (SR)(3-axis) |
| AA Filter Simulator |
Moiré reduction using SR unit (Off, Low, High) |
| Dust Removal |
Image sensor cleaning using ultrasonic vibrations "DR II" |
| Still Image |
File Format: RAW (DNG) 14bit, JPEG (Exif 2.3), DCF2.0 compliant |
| Color Space: sRGB、AdobeRGB |
| Recorded Pixels: 【3:2】L(24M:6000x4000), M(15M:4800x3200), S(7M:3360x2240), XS(2M:1920x1280)【1:1】L(16M:4000x4000), M(10M:3200x3200), S(5M:2240x2240), XS(1.6M:1280x1280) |
| Movie |
File Format: MPEG4 AVC/H.264 (MOV) |
| Recorded Pixels: Full HD (1920x1080, 60p/30p/24p), Sound: Built-in stereo microphone |
| Recording Time: Up to 25 minutes or 4GB; automatically stops recording if the internal temperature of the camera becomes high. |
| Storage Medium |
Internal Memory (Approx. 2GB), |
| SD/SDHC/SDXC Memory Card (Conforms to UHS-I standards) |
| Type |
Hybrid AF (Image plane phase-matching and Contrast detection) |
| Focus Mode |
Auto-area AF, Zone AF, Select AF, Pinpoint AF, Tracking AF, Continuous AF, MF, Snap, ∞ |
| Full Press Snap |
Performs shooting by focusing at the Snap distance with a single press of the Shutter Release Button or a touch of the LCD Monitor |
| Face/Eye Detection |
ON, Use only in Auto-area, OFF |
| Focus Range (From lens face) |
Normal: Approx. 0.2m～∞, Macro Mode: Approx. 0.12m～0.24m |
| Exposure |
|
| Exposure Mode |
Program AE, Aperture Priority AE, Shutter Priority AE, Manual Exposure |
| Metering Mode |
Multi-segment, Center-weighted, Spot, Highlight-weighted |
| Shutter Speed |
1/4000 sec. - 30 sec. (Limit by aperture setting F2.8: 1/2500 sec, F5.6 or greater: 1/4000 sec.) |
| Timed Exposure (10sec. - 20min.), Bulb, Time |
| EV Compensation |
Still Image: ±5EV, 1/3EV steps, Movie: ±2EV, 1/3EV steps |
| ND Filter (2EV) |
AUTO, ON, OFF |
| Crop |
50mm, 71mm, OFF |
| Image Control |
Standard, Vivid, Monotone, Soft Monotone, Hard Monotone, Hi-Contrast B&W, Positive Film, Bleach Bypass, Retro, Cross Processing, HDR Tone, Custom1, Custom2 |
| Adjust parameters: Saturation, Hue, High/Low Key Adjustment, Contrast, Contrast (Highlight), Contrast (Shadow), Sharpness, Shading, Clarity, Toning, Filter Effect, Grain Effect, HDR Tone Level, Color Tone (Adjust parameter varies depending on the selected image setting) |
| Dynamic Range Correction |
Highlight Correction, Shadow Correction |
| Noise Reduction |
Slow Shutter Speed Noise Reduction, High-ISO Noise Reduction |
| Horizon Correction |
SR On: correction up to 1 degrees, SR Off: correction up to 1.5 degrees |
| Display |
Display magnification (4x, 16x), Grid display (4x4 Grid, 3x3 Grid), Histogram, Bright area warning, Electronic Level |
| Playback View |
Single frame, Multi-image (20, 48 frames), Display magnification (up to 16x, 100% view and Quick Zoom view available), Histogram (Y histogram, RGB histogram), Grid display (3x3 Grid, 4x4 Grid), Bright area warning, Auto Image Rotation, |
| Base Parameter Adjustment |
Normal editing, Monotone editing |
| Parameter: Brightness, Saturation, Filter Effect, Hue, Toning, Contrast, Sharpness (Adjust parameter varies depending on the selected editing setting) |
| RAW Development |
Aspect Ratio, JPEG Recorded Pixels, Color Space, White Balance, Image Control, Peripheral Illumination Correction, Sensitivity, High-ISO Noise Reduction, Shadow Correction |
| |
Delete, Protect, Image Rotation, Image Copy, File Transfer, Resize, Cropping (Aspect ratio and Slant adjustment available), Levels Adjustment, White Balance Adjustment, Color Moiré Correction, Movie Edit (Cut), Movie Edit (Divide) |
| Edit |
3.0 inch TFT color LCD (aspect ratio 3:2), Approx. 1037K dots, Wide viewing angle, Air-gapless tempered glass |
| Type |
|
| |
|
| Touch Screen |
Capacitive sensing method |
| Adjustments |
Brightness, Saturation, Blue/Amber, Green/Magenta, Outdoor View Setting: ±2 Steps |
| Standards |
IEEE 802.11b/g/n (HT20) (Wireless LAN standard protocol) |
| Frequency (Center Frequency) |
2412MHz～2462MHz (1ch～11ch) |
| Security |
Authentication: WPA2, Encryption: AES |
| Standards |
Bluetooth® v4.2 BLE(Bluetooth Low Energy) |
| Frequency (Center Frequency) |
2402MHz～2480MHz (CH0～CH39) |
| USB Type-CTM |
Battery Recharge/Power Supply (Optional AC Adapter required), Data Transfer: MTP, Video output: DisplayPort over USB-C (DisplayPort Alternative Mode) |
| Hotshoe |
Compatible with P-TTL Auto Flash |
| Flash Mode: Flash On, Flash On+Red-eye, Slow-speed Sync, Slow Sync+Red-eye |
| Flash Exposure Compensation: -2.0 -+1.0 |
| Lens adapter pin |
Available |
| Battery Type |
Rechargeable Battery DB-110 |
| AC Adapter |
AC Adapter Kit K-AC166(Optional) |
| Battery Life |
Number of recordable images: Approx. 200 images, |
| * With a fully-charged Rechargeable Lithium-ion Battery under the temperature at 23°C. Tested in compliance with CIPA standard. Actual results may vary depending on the shooting condition. |
| Playback time: Approx. 180 minutes |
| * The playback time is a guide based on RICOH's measurement method . The actual number differs according to usage conditions. |
| Dimensions |
Approx. 109.4(W)×61.9(H)×35.2(D)mm (excluding protrusions) |
| Weight |
Approx. 262g (Included dedicated battery and SD memory card), Approx. 232g (Body only) |
