Transducer Size (millimeters): 40
Operating Principle: Dynamic
Frequency Response: 5Hz – 35Khz
Impedance: 32Ω
Sensitivity: 110dB/V
Maximum Input Power: 1700mW, 1% THD @ 1kHz
Ear Coupling: Circumaural
Ambient Noise Attenuation: 20dBA
Connection Type: Dual TRRS Cable Attachments
Acoustic Principle: Permanently polarized
Active Electronics: JFET impedance converter
Polar Pattern: Omnidirectional
Frequency Range: 20Hz - 20kHz
Signal-to-Noise Ratio: 67dB
Equivalent Noise Level (A-Weighted): 27dBA Typical
Maximum SPL: 106dB SPL RMS (Plug-In Power, 1% THD) 123dB SPL RMS (Plug-In Power, 10% THD)
Maximum Output Level: 307mV (@ 1kHz, 10% THD into 1KΩ load)
Sensitivity: 38dB re 1 Volt/Pascal (12.59 mV @ 94 dB SPL) +/- 3 dB @ 1kHz
Dynamic Range: 92dB @ max input Connection Type: 3.5mm bayonet jack (for NTH-100)
