Image Sensor
ASPECT RATIO
3:2
NUMBER OF PIXELS (EFFECTIVE)
Approx. 50.1 megapixels
NUMBER OF PIXELS (TOTAL)
Approx. 50.5 megapixels
SENSOR TYPE
35mm full frame (35.9 x 24.0mm), Exmor RS CMOS sensor
ANTI-DUST SYSTEM
Yes (Charge protection coating on Optical Filter and ultrasonic vibration mechanism)
Recording (still images)
RECORDING FORMAT
JPEG (DCF Ver. 2.0, Exif Ver. 2.32, MPF Baseline compliant), HEIF (MPEG-A MIAF compliant), RAW (Sony ARW 4.0 format compliant)
IMAGE SIZE (PIXELS) [3:2]
35mm full frame L: 8640 x 5760 (49.7M), M: 5616 x 3744 (21M), S: 4320 x 2880 (12.4M), APS-C M: 5616 x 3744 (21M), S: 4320 x 2880 (12.4M)
IMAGE SIZE (PIXELS) [4:3]
35mm full frame L: 7680 x 5760 (44.2M), M: 4992 x 3744 (18.6M), S: 3840 x 2880 (11M), APS-C M: 4992 x 3744 (18.6M), S: 3840 x 2880 (11M)
IMAGE SIZE (PIXELS) [16:9]
35mm full frame L: 8760 x 4864 (42M), M: 5616 x 3160 (17.7M), S: 4320 x 2432 (10.5M), APS-C M: 5616 x 3160 (17.7M), S: 4320 x 2432 (10.5M)
IMAGE SIZE (PIXELS) [1:1]
35mm full frame L: 5760 x 5760 (33M), M: 3744 x 3744 (14M), S: 2880 x 2880 (8.2M), APS-C M: 3744 x 3744 (14M), S: 2880 x 2880 (8.2M)
IMAGE QUALITY MODES
RAW (Compressed / Lossless Compressed / Uncompressed), JPEG (Extra fine / Fine / Standard / Light), HEIF (4:2:0 / 4:2:2) (Extra fine / Fine / Standard / Light)
PICTURE EFFECT
-
CREATIVE STYLE
-
PICTURE PROFILE
Yes (Off / PP1-PP11) Parameters: Black level, Gamma (Movie, Still, S-Cinetone, Cine1-4, ITU709, ITU709 (800%), S-Log2, S-Log3, HLG, HLG1-3), Black Gamma, Knee, Color Mode, Saturation, Color Phase, Color Depth, Detail, Copy, Reset
CREATIVE LOOK
ST, PT, NT, VV, VV2, FL, IN, SH, BW, SE, Custom Look (1-6)
DYNAMIC RANGE FUNCTIONS
Off, Dynamic Range Optimizer
COLOUR SPACE
sRGB standard (with sYCC gamut), Adobe RGB standard and Rec. ITU-R BT.2100 standard (BT.2020 gamut).1
14BIT RAW
Yes
Recording (movie)
RECORDING FORMAT
XAVC S, XAVC HS
VIDEO COMPRESSION
XAVC S: MPEG-4 AVC/H.264, XAVC HS: MPEG-H HEVC/H.265
AUDIO RECORDING FORMAT
LPCM 2ch(48kHz 16bit), LPCM 2ch(48kHz 24bit)2, LPCM 4ch(48kHz 24bit)2, MPEG-4 AAC-LC 2ch3
COLOUR SPACE
Rec. ITU-R BT.2100 standard compatible (BT.2020 gamut)4
PICTURE EFFECT
-
CREATIVE STYLE
-
PICTURE PROFILE
Yes (Off / PP1-PP11) Parameters: Black level, Gamma (Movie, Still, S-Cinetone, Cine1-4, ITU709, ITU709 (800%), S-Log2, S-Log3, HLG, HLG1-3), Black Gamma, Knee, Color Mode, Saturation, Color Phase, Color Depth, Detail, Copy, Reset
CREATIVE LOOK
ST, PT, NT, VV, VV2, FL, IN, SH, BW, SE, Custom Look (1-6)
MOVIE RECORDING SYSTEM (XAVC HS 8K)
7680 x 4320 (4:2:0, 10bit, NTSC) (Approx.): 30p(400Mbps / 200 Mbps), 24p(400Mbps / 200 Mbps), 7680 x 4320 (4:2:0, 10bit, PAL) (Approx.): 25p(400Mbps / 200 Mbps)
MOVIE RECORDING SYSTEM (XAVC HS 4K)
3840 x 2160 (4:2:0, 10bit, NTSC) (Approx.): 120p (200Mbps), 60p (150Mbps / 75Mbps / 45Mbps), 24p (100Mbps / 50Mbps / 30Mbps); 3840 x 2160 (4:2:0, 10bit, PAL) (Approx.): 100p (200Mbps), 50p (150Mbps / 75Mbps / 45Mbps); 3840 x 2160 (4:2:2, 10bit, NTSC) (Approx.): 120p (280Mbps), 60p (200Mbps / 100Mbps), 24p (100Mbps / 50Mbps); 3840 x 2160 (4:2:2, 10bit, PAL) (Approx.): 100p (280Mbps), 50p (200Mbps / 100Mbps)
MOVIE RECORDING SYSTEM (XAVC S 4K)
3840 x 2160 (4:2:0, 8bit, NTSC) (Approx.): 120p (200Mbps), 60p (150Mbps), 30p (100Mbps / 60Mbps), 24p (100Mbps / 60Mbps); 3840 x 2160 (4:2:0, 8bit, PAL) (Approx.): 100p (200Mbps), 50p (150Mbps), 25p (100Mbps / 60Mbps); 3840 x 2160 (4:2:2, 10bit, NTSC) (Approx.): 120p (280Mbps), 60p (200Mbps), 30p (140Mbps), 24p (100Mbps); 3840 x 2160 (4:2:2, 10bit, PAL) (Approx.): 100p (280Mbps), 50p (200Mbps), 25p (140Mbps)
MOVIE RECORDING SYSTEM (XAVC S HD)
1920 x 1080 (4:2:0, 8bit, NTSC) (Approx.): 120p (100Mbps / 60Mbps), 60p (50Mbps / 25Mbps), 30p (50Mbps / 16Mbps), 24p (50Mbps); 1920 x 1080 (4:2:0, 8bit, PAL) (Approx.): 100p (100Mbps / 60Mbps), 50p (50Mbps / 25Mbps), 25p (50Mbps / 16Mbps); 1920 x 1080 (4:2:2, 10bit, NTSC) (Approx.): 60p (50Mbps), 30p (50Mbps), 24p (50Mbps); 1920 x 1080 (4:2:2, 10bit, PAL) (Approx.): 50p (50Mbps), 25p (50Mbps)
MOVIE RECORDING SYSTEM (XAVC S-I 4K)
3840 x 2160 (4:2:2, 10bit, NTSC) (Approx.): 60p (600Mbps), 30p (300Mbps), 24p (240Mbps); 3840 x 2160 (4:2:2, 10bit, PAL) (Approx.): 50p (500Mbps), 25p (250Mbps)
MOVIE RECORDING SYSTEM (XAVC S-I HD)
1920 x 1080 (4:2:2, 10bit, NTSC) (Approx.): 60p (222Mbps), 30p (111Mbps), 24p (89Mbps); 1920 x 1080 (4:2:2, 10bit, PAL) (Approx.): 50p (185Mbps), 25p (93Mbps)
SLOW & QUICK MOTION (SHOOTING FRAME RATE)
NTSC mode: 1fps,2fps,4fps,8fps,15fps,30fps,60fps,120fps, 240fps56, PAL mode: 1fps,2fps,3fps,6fps,12fps,25fps,50fps,100fps, 200fps56
MOVIE FUNCTIONS
Audio Level Display, Audio Rec Level, PAL/NTSC Selector, Proxy Recording (1280 x 720 (6Mbps), 1920 x 1080(9Mbps), 1920 x 1080(16Mbps)), TC/UB, Auto Slow Shutter, Gamma Disp. Assist, RAW Output(HDMI)
Recording System
LOCATION INFORMATION LINK FROM SMARTPHONE
Yes
MEDIA
SD memory card, SDHC memory card (UHS-I/II compliant), SDXC memory card (UHS-I/II compliant), CFexpress Type A memory card
MEMORY CARD SLOT
SLOT1: Multi slot for SD (UHS-I/II compliant) memory card/CFexpress Type A card, SLOT2: Multi slot for SD (UHS-I/II compliant) memory card/CFexpress Type A card
RECORDING MODE ON 2 MEMORY CARDS
Simult. Rec, Sort, Auto Switch Media, Copy
Noise Reduction
NOISE REDUCTION
Long exposure NR: On/Off, available at shutter speeds longer than 1 sec.,High ISO NR: Normal / Low / Off
White balance
WHITE BALANCE MODES
Auto / Daylight / Shade / Cloudy / Incandescent / Fluorescent / Flash / Underwater / Color Temperature (2500 to 9900K) & color filter / Custom
SHUTTER AWB LOCK
Yes (Shut. Halfway Down / Cont. Shooting / Off)
Focus
FOCUS TYPE
Fast Hybrid AF (phase-detection AF / contrast-detection AF)
FOCUS SENSOR
Exmor RS CMOS sensor
FOCUS POINT
35mm full frame: 759 points (phase-detection AF), APS-C mode with FF lens: 759 points (phase-detection AF), with APS-C lens: 575 points (phase-detection AF) / 425 points (contrast-detection AF)
FOCUS SENSITIVITY RANGE
EV-4 to EV20 (ISO100 equivalent with F2.0 lens attached)
FOCUS MODE
AF-S (Single-shot AF), AF-C ( Continuous AF), DMF (Direct Manual Focus), Manual Focus
FOCUS AREA
Wide / Zone / Center / Flexible Spot / Expanded Flexible Spot / Tracking
EYE AF
Still images: Human (Right/Left Eye Select) / Animal (Right/Left Eye Select) / Bird, Movie: Human (Right/Left Eye Select)
OTHER FEATURES
Predictive control, Focus lock, AF Track Sens. (Still), AF Subj. Shift Sensitivity (Movie), AF Transition Speed (Movie), Switch V/H AF Area, AF Area Regist., Circ. of Focus Point
AF ILLUMINATOR
Yes (with Built-in LED type)
AF ILLUMINATOR RANGE
Approx. 0.3m - approx. 3.0m (with FE 28-70mm F3.5-5.6 OSS lens attached)
FOCUS TYPE WITH LA-EA3 (SOLD SEPARATELY)
Phase-detection
Exposure
METERING TYPE
1200-zone evaluative metering
METERING SENSOR
Exmor RS CMOS sensor
METERING SENSITIVITY
EV-3 to EV20 (at ISO100 equivalent with F2.0 lens attached)
METERING MODE
Multi-segment, Center-weighted, Spot, Spot Standard/Large, Entire Screen Avg., Highlight
EXPOSURE COMPENSATION
+/- 5.0EV (1/3 EV, 1/2 EV steps selectable) (with exposure compensation dial: +/- 3EV (1/3 EV steps))
EXPOSURE BRACKETING
Bracket: Cont., Bracket: Single, 3/5/9 frames selectable. (Ambient light, Flash light)
AE LOCK
Locked when shutter button is pressed halfway. Available with AE lock button. (On/Off/Auto)
EXPOSURE MODES
AUTO(iAuto), Programmed AE (P), Aperture priority (A), Shutter-speed priority (S), Manual (M), Movie (Programmed AE (P) / Aperture priority (A) / Shutter-speed priority (S) / Manual (M) / Flexible Exp. Mode), Slow & Quick Motion (Programmed AE (P) / Aperture priority (A) / Shutter-speed priority (S) / Manual (M) / Flexible Exp. Mode)
ISO SENSITIVITY (RECOMMENDED EXPOSURE INDEX)
Still images: ISO 100-32000 (ISO numbers up from ISO 50 to ISO 102400 can be set as expanded ISO range.), AUTO (ISO 100-12800, selectable lower limit and upper limit), Movies: ISO 100-32000 equivalent, AUTO (ISO 100-12800, selectable lower limit and upper limit)
ANTI-FLICKER SHOOT.
Yes
SCENE SELECTION
-
Viewfinder
VIEWFINDER TYPE
1.6 cm (0.64 type) electronic viewfinder (color)
NUMBER OF DOTS
9 437 184 dots
FIELD COVERAGE
100%
MAGNIFICATION
Approx. 0.90 x (with 50mm lens at infinity, -1m-₁)
DIOPTRE ADJUSTMENT
-4.0 to +3.0m-₁
EYE POINT
Approx. 25mm from the eyepiece lens, 21mm from the eyepiece frame at -1m-₁ (CIPA standard)
DISPLAY FUNCTION
Histogram, Real-time image-adjustment display, Digital level gauge, Grid line, Focus check, Peaking MF, Zebra, Movie marker, Emph disp dur REC
FINDER FRAME RATE SELECTION
STD 60fps / HI 120fps / HI+ 240fps7
LCD Screen
MONITOR TYPE
7.5cm (3.0-type) type TFT
NUMBER OF DOTS
1,440,000 dots
TOUCH PANEL
Yes
BRIGHTNESS CONTROL
Manual (5 steps between -2 and +2), Sunny Weather mode
ADJUSTABLE ANGLE
Up by Approx. 107 degrees, Down by Approx. 41 degrees
FOCUS MAGNIFIER
Yes, Focus Magnifier (35mm full frame: 4.2x / 8.5x, APS-C: 2.7x / 5.5x)
Other Features
PLAYMEMORIES CAMERA APPS™
-
CLEAR IMAGE ZOOM
Still images:Approx. 2x,Movies:Approx. 1.5x (4K), Approx. 2x (HD)
DIGITAL ZOOM
Smart zoom (Still images):35mm full frame: M:Approx. 1.5x, S:Approx. 2x, APS-C: S:Approx. 2x, Digital zoom (Still images):35mm full frame: L:Approx. 4x, M:Approx.6.1x, S:Approx. 8x,APS-C: M:approx. 4x, S: approx. 5.2x, Digital zoom (Movie):35mm full frame: Approx. 4x, APS-C: Approx. 4x
FACE DETECTION
Face/Eye Priority in AF, Face Priority in Multi Metering, Regist. Faces Priority
SELF-PORTRAIT SELF-TIMER
-
OTHERS
Interval Recording, ISO AUTO Min. SS, Bright Monitoring, Copyright Info, Set File Name, Save/Import Settings, Help guide, Video Light Mode, Zoom Ring Rotate
Shutter
TYPE
Electronically-controlled, vertical-traverse, focal-plane type
SHUTTER TYPE
Mechanical shutter/Electronic shutter
SHUTTER SPEED
Still images, Single shot Mechanical Shutter:1/8000 to 30 sec, Bulb; AUTO: 1/32000 to 30 sec, Bulb; Electronic Shutter: 1/32000 to 30 sec; Still images, Continous shooting Mechanical; Shutter:1/8000 to 30 sec; AUTO: 1/32000 to 1/2 sec; Electronic Shutter: 1/32000 to 1/2 sec; Movies: 1/8000 to 1/4(1/3 steps), up to 1/60 in AUTO mode (up to 1/30 in Auto slow shutter mode)
FLASH SYNC. SPEED
(Mechanical shutter), (Flash Sync. Priority) is (ON) or (AUTO):1/400 sec (35mm full frame), 1/500 sec (APS-C), (Flash Sync. Priority) is (OFF):1/320 sec (35mm full frame), 1/400 sec (APS-C), (Electrical shutter), 1/200 sec (35mm full frame), 1/250 sec (APS-C)
ELECTRONIC FRONT CURTAIN SHUTTER
Yes
SILENT SHOOTING
Yes (ON/OFF)
Image Stabilization
TYPE
Image Sensor-Shift mechanism with 5-axis compensation (Compensation depends on lens specifications)
COMPENSATION EFFECT
5.5 stops (based on CIPA standard. Pitch/yaw shake only. With Planar T* FE 50mm F1.4 ZA lens mounted. Long exposure NR off.)
Flash Control
TYPE
-
GUIDE NO.
-
FLASH COVERAGE
-
CONTROL
Pre-flash TTL
FLASH COMPENSATION
+/- 3.0 EV (switchable between 1/3 and 1/2 EV steps)
FLASH MODES
Flash off, Autoflash, Fill-flash, Slow Sync., Rear Sync., Red-eye reduction (on/off selectable), Wireless8, Hi-speed sync.8
RECYCLING TIME
-
EXTERNAL FLASH COMPATIBILITY
Sony α System Flash compatible with Multi Interface Shoe, attach the shoe adaptor for flash compatible with Auto-lock accessory shoe
FE LEVEL LOCK
Yes
WIRELESS CONTROL
Yes (Light signal: Available with Fill-flash, Slow Sync., Hi-speed sync. / Radio signal: Available with Fill-flash, Rear Sync., Slow Sync., Hi-speed sync.)
Drive
DRIVE MODES
Single Shooting, Continuous shooting (Hi+/Hi/Mid/Lo selectable), Self-timer, Self-timer (Cont.), Bracket: Single, Bracket: Cont., White Balance bracket, DRO bracket
CONTINUOUS DRIVE SPEED (APPROX. MAX.)
AUTO/Electronic Shutter: Continuous shooting: Hi+: 30 fps, Hi: 20 fps, Mid: 15fps, Lo: 5 fps,9101112 Mechanical Shutter: Continuous shooting: Hi+: 10 fps, Hi: 8 fps, Mid: 6fps, Lo: 3 fps
NO. OF RECORDABLE FRAMES (APPROX.)
JPEG Extra fine L: 182 frames, JPEG Fine L: 400 frames, JPEG Standard L: 400 frames, RAW: 238 frames, RAW & JPG: 192 frames, RAW (Lossless Compression): 96 frames, RAW (Lossless Compression) & JPG: 83 frames, RAW (Uncompressed): 82 frames, RAW (Uncompressed) & JPG: 78 frames
SELF-TIMER
10 sec. delay / 5 sec. delay / 2 sec. delay / Continuous self-time / Bracketing self-timer
PIXEL SHIFT MULTI SHOOTING
Yes (4 shots / 16 shots)1
Playback
PHOTO CAPTURE
Yes
MODES
Single (with or without shooting information Y RGB histogram & highlight / shadow warning),Index view,Enlarged display mode (L: 21.6x, M: 14.0x, S: 10.8x),Auto Review,Image orientation,Folder selection (Date / Still / Movie),Protect,Rating,Display as Group
Interface
PC INTERFACE
Mass-storage / MTP
MULTI / MICRO USB TERMINAL
Yes (SuperSpeed USB 10Gbps (USB 3.2) compatible)
BLUETOOTH
Yes (Bluetooth Standard Ver. 5.0 (2.4GHz band))
WIRELESS LAN (BUILT-IN)
Yes (Wi-Fi Compatible, IEEE 802.11a/b/g/n/ac (2.4GHz band/5GHz band))1314
MULTI INTERFACE SHOE
Yes (with Digital Audio Interface)15
MIC TERMINAL
Yes (3.5 mm Stereo minijack)
SYNC TERMINAL
Yes
HEADPHONE TERMINAL
Yes (3.5 mm Stereo minijack)
VERTICAL GRIP CONNECTOR
Yes
LAN TERMINAL
Yes (1000BASE-T, 100BASE-TX, 10BASE-T)
FUNCTIONS
FTP Transfer Func.(Wired LAN, USB Tethering, Wi-Fi)., View on Smartphone,Remote control via Smartphone, NFC One-touch remote,PC Remote, BRAVIA Sync (Control for HDMI), PhotoTV HD
Audio
MICROPHONE
Built-in, stereo
SPEAKER
Built-in, monaural
Print
COMPATIBLE STANDARDS
Exif Print, Print Image Matching III
Custom function
TYPE
Custom key settings,Programmable Setting (Body 3 sets /memory card 4 sets),My Dial Settings,My Menu,Reg Cust Shoot Set
Lens Compensation
SETTING
Peripheral Shading, Chromatic Aberration, Distortion
Power
SUPPLIED BATTERY
One rechargeable battery pack NP-FZ100
BATTERY LIFE (STILL IMAGES)
Approx. 430 shots (Viewfinder) / approx. 530 shots (LCD monitor) (CIPA standard)
BATTERY LIFE (MOVIE, ACTUAL RECORDING)
Approx. 90 min. (Viewfinder) / Approx. 95 min. (LCD monitor) (CIPA standard)
BATTERY LIFE (MOVIE, CONTINUOUS RECORDING)
Approx. 145 min. (Viewfinder) / Approx. 150 min. (LCD monitor) (CIPA standard)
INTERNAL BATTERY CHARGE
Yes (Available with USB Type-C Terminal. USB Power Delivery compatible)
POWER CONSUMPTION WITH VIEWFINDER
Still images: approx. 4.6W (with FE 28-70mm F3.5-5.6 OSS lens attached), Movies: approx. 6.8W (with FE 28-70mm F3.5-5.6 OSS lens attached)
POWER CONSUMPTION WITH LCD SCREEN
Still images: approx. 3.7W (with FE 28-70mm F3.5-5.6 OSS lens attached), Movies: approx. 6.6W (with FE 28-70mm F3.5-5.6 OSS lens attached)
USB POWER SUPPLY
Yes (Available with USB Type-C Terminal. USB Power Delivery compatible)
Others
OPERATING TEMPERATURE
32 - 104 degrees F / 0 - 40 degrees C
Size & Weight
WEIGHT (WITH BATTERY AND MEMORY CARD INCLUDED)
Approx. 737 g, approx. 1 lb 10.0 oz
DIMENSIONS (W X H X D)
Approx. 128.9mm x 96.9mm x 80.8mm, Approx. 128.9mm x 96.9mm x 69.7mm (FROM GRIP TO MONITOR), Approx. 5 1/8 x 3 7/8 x 3 1/4 inches, Approx. 5 1/8 x 3 7/8 x 2 3/4 inches (FROM GRIP TO MONITOR)
