Name: Sony Cinema Line FX9 Full Frame E-mount Camera
Brand: Sony
SKU: 117241
Availability: OutOfStock
Rating: 4.6 (117 reviews)

117241

Found a better price? We'll match it!^* Price Match Now

Product Description
Specifications
What's in the Box?

Sony Cinema Line FX9 Full Frame E-mount Camera

Key Features

6K Full-Frame Exmor R CMOS Sensor
15 Stops of Dynamic Range, Dynamic HDR
DCI 4K and UHD 4K up to 59.94p
HD Recording up to 150/180 fps
Quad Full HD 120p Raw with XDCA-FX9 Unit
Sony E-Mount
10-Bit 4:2:2 XAVC-I up to 600 Mb/s
Auto-HD, AF, 7-Stop ND Filter, 3D LUTs
Dual Base ISO up to 102,400, HLG Mode
12G/6G/3G-SDI & HDMI Output up to 4K

The v3.0 firmware update offers:

S700 protocol over Ethernet
B4 lens support:
S16 scanning mode (up to 1080p at rates up to 180 fps)
B4 lens control using the LA-EB1 lens mount adapter
ALAC (Auto Lens Aberration Correction) function
Assignable center scan
Anamorphic lens support
Clip naming (Cam ID + Reel#)
Real-time tracking (touch-tracking autofocus)
Additional items can be modified in the status screen
SR Live for HDR metadata support
Recording proxy clip real-time transfer
Camcorder network setup using smartphone app
Remote control using smartphone over USB tethering
USB tethering activated using iOS 14 iPhone and iPad

Whether you're shooting documentaries, events, reality TV, education, or corporate productions, the PXW-FX9 XDCAM 6K Full-Frame Camera System from Sony has you covered with its powerful and flexible 4K interchangeable lens camera system. The PXW-FX9 features a full-frame, oversampled 6K Exmor R CMOS sensor that allows you to capture 4K images with cinematic depth of field. The camera's E-mount is machined from stainless steel and allows you to use E-mount lenses.

Lens Mount Sony E
Lens Communication Yes
Sensor Resolution Actual: 20.5 Megapixel
Effective: 19 Megapixel
Sensor Type 35.7 x 18.8 mm (Full-Frame) CMOS
Built-In ND Filter 4 to 128 Stop Electronic ND Filter
ISO Sensitivity 800 to 4000 (Native)
320 to 102,400 (Expanded)
Shutter Type Electronic Rolling Shutter
Shutter Speed 1/1 to 1/8000 sec
Shutter Angle 6 to 360°
Gain -3 to 18 dB
Advertised Dynamic Range 15 Stops
Signal-to-Noise Ratio 57 dB
Internal Recording
Recording Modes XAVC-I 4:2:2 10-Bit:
4096 x 2160p at 23.98/24/25/29.97/50/59.94 fps
3840 x 2160p at 23.98/25/29.97/50/59.94 fps (240 to 600 Mb/s)
1920 x 1080p at 23.98/25/29.97/50/59.94/100/120 fps (89 to 222 Mb/s)
1920 x 1080i at 50/59.94 fps (112 Mb/s)
XAVC-L 4:2:2 10-Bit:
3840 x 2160p at 23.98/25/29.97/50/59.94 fps (100 to 150 Mb/s)
1920 x 1080p at 23.98/25/29.97/50/59.94/100/120 fps (25 to 50 Mb/s)
1920 x 1080i at 50/59.94 fps (50 Mb/s)
MPEG HD422 4:2:2 10-Bit:
1920 x 1080p at 23.98/25/29.97 fps (50 Mb/s)
1920 x 1080i at 50/59.94 fps (50 Mb/s)
XAVC Proxy 4:2:0 10-Bit:
1920 x 1080p (9 Mb/s)
1280 x 720p (6 to 9 Mb/s)
640 x 360p (3 Mb/s)
Variable Frame Rates DCI 4K: 1 to 60 fps
UHD: 1 to 60 fps
1080p: 1 to 179.82 fps
1080p (Windowed): 1 to 119.88 fps
Gamma Curve HDR-HLG, S Cinetone, Sony S-Log 3, Standard
Audio Recording XAVC: 4-Channel 24-Bit 48 kHz LPCM Audio
Proxy: 2-Channel AAC Audio
Still Image Support Not Specified by Manufacturer
External Recording
Raw Output External Recorder In Raw Mode:
4096 x 2160 16-Bit at 23.98/24.00/25/29.97 fps
3840 x 2196 16-Bit at 100/119.88 fps
3840 x 2160 16-Bit at 23.98/25/29.97/50/59.94 fps
2048 x 1080 16-Bit at 23.98/25/29.97/50/59.94/100/119.88/150/179.82 fps
IP Streaming Yes
Media/Memory Card Slot Slot 1: XQD
Slot 2: XQD
Dual Slot: SD/SDHC/SDXC/Memory Stick Duo Hybrid
Video I/O 1 x BNC (12G-SDI) Output
1 x BNC (3G-SDI) Output
1 x HDMI (HDMI 2.0) Output
Audio I/O 2 x XLR 3-Pin Mic/Line (+48 V Phantom Power) Input
1 x 1/8" / 3.5 mm TRS Stereo Headphone Output
Built-In Microphone Type Mono
Other I/O 1 x BNC (Genlock) Data Input
1 x BNC (Timecode) Data Input/Output
1 x 2.5 mm Sub-Mini (LANC) Control
1 x USB Micro-B (USB 3.2 / 3.1 Gen 1) Data
Wireless 2.4 / 5 GHz Wi-Fi 5 (802.11ac)
Size 3.5"
Resolution 2,760,000 Dot
Display Type Included External Touchscreen LCD
EVF
Type Optional, Not Included
Power
Battery Type Sony BP-U Series
Power I/O 1 x Barrel (18 to 20.5 VDC) Input
Power Consumption 35.2 W
Environmental
Operating Temperature 32 to 104°F / 0 to 40°C
Storage Temperature -4 to 140°F / -20 to 60°C
Tripod Mounting Thread 3/8"-16 Female (Bottom)
1/4"-20 Female (Bottom)
Accessory Mount 1 x Intelligent Hot Shoe
1 x Cold Shoe Mount
2 x 3/8"-16 Female
6 x 1/4"-20 Female
Dimensions (W x H x D) 5.7 x 5.6 x 9" / 146 x 142.5 x 229 mm (Without Protrusions)
Weight 4.4 lb / 2 kg
10.58 lb / 4.8 kg
Packaging Info
Package Weight 18 lb
Box Dimensions (LxWxH) 60 x 20 x 13"
