Sony HXR-NX800 Professional Camcorder

Key Features

Single 1" Exmor RS CMOS Sensor
Up to UHD 4K60 HDR with HLG
HDMI Output, 2.4/5 GHz Live Streaming
AI-Powered Autofocus & Auto-Framing
20x Optical, 30x Clear Image Zoom in 4K
4K120 & 1080p240 High Frame Rates
XAVC S-I, HS-L, S-L, HD/QFHD Recording
S-Cinetone, ITU709, 709tone, HLG Options
Dual CFexpress Type-A/SD Card Slots
4-Channel Audio, Monitor & Control App

On-the-go creators looking for rapid autofocusing, auto-framing, and quick content sharing in a compact form can turn to the Sony HXR-NX800 4K HDR 1" Sensor NXCAM Camcorder. Geared for high mobility, this professional camcorder features a 1"-type Exmor RS CMOS sensor for up to UHD 4K resolution, AI-assisted autofocus and auto-framing, a variable electronic ND filter, BIONZ XR processing, and color matching with Sony Cinema Line cameras. It sports a longer 20x optical zoom and has built-in dual-band 2.4/5 GHz Wi-Fi and an Ethernet for direct streaming via RTMP/RTMPS, SRT protocols, and FTP options. Use the Sony Monitor & Control app to view your capture using your smartphone or tablet.

Sensor Resolution	Actual: 20.9 Megapixel Effective: 14 Megapixel
Image Sensor	13.2 x 8.8 mm (1"-Type) CMOS
Image Stabilization	Optical in Integrated Lens Digital
ISO Sensitivity Range	250 to 16,000
Internal Recording Modes	H.264/H.265/XAVC HS/XAVC S UHD 4K (3840 x 2160) up to 120 fps 1920 x 1080p up to 240 fps
Media/Memory Card Slot	Dual Slot: CFexpress Type A / SD (UHS-II)
Video I/O	1x HDMI (Unspecified Signal) Output
Mobile App Compatible	Yes: Android & iOS
Battery Type	Sony BP-U Series

Imaging

Sensor Resolution	Actual: 20.9 Megapixel Effective: 14 Megapixel
Image Sensor	13.2 x 8.8 mm (1"-Type) CMOS
Image Stabilization	Optical in Integrated Lens Digital
Built-In ND Filter	2 to 7 Stop Electronic ND Filter
Capture Type	Video Only

Exposure Control

Shutter Type	Electronic Rolling Shutter
Shutter Speed	1/8000 to 64 Seconds
ISO Sensitivity Range	250 to 16,000
Gain	-3 to 36 dB
Minimum Illumination	1.2 Lux
White Balance	2000 to 15,000K Presets: ATW, Auto

Focal Length	7.71 to 154.21mm (35mm Equivalent: 24 to 480mm)
Optical Zoom Ratio	20x
Max Digital Zoom	1.5x ( in UHD 4K) 2x ( in 1080p)
Maximum Aperture	f/2.8 to 4.5
Minimum Focus Distance	0.4" / 1.0 cm
Filter Size	72 mm
Focus Control	Autofocus Manual Focus

Video Capture

Internal Recording Modes	H.264/H.265/XAVC HS/XAVC S UHD 4K (3840 x 2160) up to 120 fps 1920 x 1080p up to 240 fps
Fast-/Slow-Motion Support	Yes
Gamma Curve	HDR-HLG, Rec709, S Cinetone, Sony S-Log 3
Broadcast Output	NTSC/PAL
Built-In Microphone	Stereo
Audio Recording	4-Channel 24-Bit 48 kHz LPCM Audio
IP Streaming	H.264, H.265, RTMP, RTMPS, SRT 3840 x 2160 1920 x 1080 1280 x 720

Interface

Media/Memory Card Slot	Dual Slot: CFexpress Type A / SD (UHS-II)
Video I/O	1x HDMI (Unspecified Signal) Output
Audio I/O	1x 1/8" / 3.5 mm TRS Stereo Input 2x XLR 3-Pin Input 1x 1/8" / 3.5 mm TRRS Headphone/Mic Headphone Output
Power I/O	1x USB-C
Other I/O	1x 2.5 mm Sub-Mini (Remote) Control 1x RJ45 (LAN) Control 1x USB-C (USB 3.2 / 3.1 Gen 1)
Wireless	2.4 / 5 GHz Wi-Fi 5 (802.11ac)
Mobile App Compatible	Yes: Android & iOS
Global Positioning (GPS, GLONASS, etc.)	No

Monitor

Display Type	Articulating Touchscreen LCD
Display Size	3.5"

Viewfinder

Type	Built-In Electronic
Size	0.39"
Diopter Adjustment	-4 to +3

Focus

Focus Type	Auto and Manual Focus
Autofocus Points	Phase Detection: 475

Environmental

Operating Temperature	32 to 104°F / 0 to 40°C
Storage Temperature	-4 to 140°F / -20 to 60°C

General

Battery Type	Sony BP-U Series
Power Consumption	16 W
Shoe Mount	1x Intelligent Hot Shoe
Dimensions (W x H x D)	6.9 x 7.9 x 14.63" / 175.6 x 201.3 x 371.6 mm
Weight	4.25 lb / 1.93 kg (Body Only)
