Vanguard Veo 2 Pro 233CV + PH-13 Video Head Kit

116588

inc GST
Increase value Decrease value
Found a better price? We'll match it!* Price Match Now
  • Product Description
  • Specifications
  • What's in the Box?

Vanguard Veo 2 Pro 233CV + PH-13 Video Head Kit

This VEO 2 PRO 233CV Carbon Fiber Tripod Kit with PH-13 Video Head from Vanguard supports up to 8.8 lb, measures 22.8" when folded, and includes a PH-13 pan-and-tilt head. Each of its three-section legs features an independent spread as well as twist locks for fast deployment. Together, the three legs can be adjusted in three positions at 20, 45, and 80° angles to a maximum height of 57.5" with the center column fully raised. Foam covers on each of the legs provide a secure, comfortable grip while moving the tripod, and rubber feet, each with a metal spike option, further enhance stability on a wide variety of surfaces, including soft and uneven soil.

Cameras or accessories connect to the Arca-style plate with the 1/4"-20 thread, which is secured to the tripod's pan-and-tilt head using a quick release lock. The quick release plate features a rubberized, non-slip platform with a safety pin to prevent twisting.

The PH-13 head can be panned 360° and tilted -45° to 90°. Each of these movements function independently of each other and can be locked into place. For added versatility, the center column is connected to the tripod by a fulcrum that makes balancing and locking easy.

A carry bag, low-angle adapter, two Allen wrenches, and a 3/8"-16 screw adapter are included.

  • Load Capacity: 8.8 lb, Leg Sections: 3
  • Tiltable & Rotatable Rapid Center Column
  • 360° Pan, -45 to 90° Tilt
  • Carbon Fiber Legs, Twist Locks
  • Maximum Height: 57.5"
  • Folded Length: 22.8", Weight: 3.3
  • Arca-Style Quick Release Plate
  • Pan Handle
  • Lightweight 3.3 carbon fiber tripod with PH-13 video head
  • Supports up to 8.8 lb
  • Extends to maximum height of 57.5" and folds down to 22.8"
  • Three-position legs adjust at 20, 45, and 80° angles
  • Arca-style quick release head
  • Three-section legs secure with twist locks
  • Rubber and spiked feet support tripod on various types of terrain
  • Low-angle adapter, 3/8"-16 screw adapter, Allen wrenches, and a carry bag are included
Camera Plate
Camera Plate Features    Quick Release
Camera Plate Type    Arca-type
Camera Mounting Screw    1 x 1/4"-20 Male with Locating Pin
Safety Lock    Yes
Head
Base Mount    Proprietary
Camera Platform Adjustment    Yes
Pan Handle Fittings    1 x Fixed
Bubble Level    1
Base Diameter    2.28" / 58 mm
Pan & Tilt
Panning Range    360°
Independent Pan Lock    Yes
Independent Tilt Lock    Yes
Lateral Tilt    -45° to +90°
Legs
Leg Lock Type    Twist Lock
Leg Positions    3 Positions
Independent Leg Spread    Yes
Leg Sections    3
Leg Diameter    0.91" / 23 mm
Bubble Level    Yes
Feet Features    Rubber, Spiked
Center Column
Center Column Features    Ballast Hook
Center Column Sections    1
Center Column Extension Type    Rapid
General
Load Capacity    8.8 lb / 3.99 kg
Maximum Working Height    57.5" / 1.46 m
Max Height without Center Column    46.5" / 118.11 cm
Folded Length    22.8" / 57.91 cm
Materials    Carbon Fiber, Magnesium
Weight    3.3 lb / 1.50 kg
  • Vanguard VEO 2 PRO 233CV Carbon Fiber Tripod with PH-13 Video Head
  • 3-Section Carbon Fiber Tripod Legs
  • VEO 2 PH-13 Pan Head with Pan Handle
  • Low-Angle Adapter
  • Tripod Bag
  • Spiked Feet
  • 3/8"-16 Screw Adapter
  • 2 x Allen Wrench
